Page 144 - BallyMidway YELLOW Parts Catalog 16-9147-B

(Used on all games)
Plumb Bob and Wire Assembly
A-8476
(Mounted on Mechanism Panel)
.."",._ -- -- -~ 01-3444
Upper Tilt Bracket
+----- ---12-6231
Plumb Bob Wire
/-1- - -- -- - 20-6502-A
Plumb Bob
01 -96-- --- --
Switch Limit Bracket
SW-1A-117----- ..•••••.
Shake Switch
01-2642 -14A-- - ------it-
Mounting Bracket
_- 4406-01120-00
Wing Nut #6 -32
-H-- - 01-3445
Lower Tilt Bracket
Tilt Switch Assembly
B-8306-1
(Mounted under Playfield)
Used on: Atlantis (2006)
Transporter (2008)
2-10 @a!fy/MIDWAY
