Page 121 - BallyMidway YELLOW Parts Catalog 16-9147-B

Replaceable Lamps & Sockets
Pool Radic Dude Harl Bugs
Part Number Description 2014 2015 2016 20001 20009
Game and Part Quantity
24·6549 #44 Light Bulb 28 50 54 67 58
24·8704 #89 Ught Bulb 11 4 8 5 6
24·8768 #555 Ught Bulb 6 5 36 45 53
24·8802 #906 Light Bulb 3 1 7 12 12
Gillign PartyZ OrWho BlackR Add am
. Part Number Description 20003 20004 20006 20013 20017
Game and Part Quantity
24·6549 #44 light Bulb 53 75 49 49 40
24-6591 #455 Light Bulb 7
24·8704 #89 light Bulb 5 9 1 6
24·8768 #555 Ught Bulb 85 73 92 77 56
24·8802 #906 Ught Bulb 12 11 11 12 10
#906 Bulb
24-8802
#555 Bulb
24-8768
Twist Socket
24-8803
Twist Socket
. 24-8767
#455 Lamp
24·6591
o
24·8817 Socket w/o Diode. White
24·8818 Socket w/o Diode, Black
24·8819 Socket w/Olode, White
(General Illumination)
(Flash Lamps)
(Controlled Lighting)
Note: #555 and #906 bulbs are interchangeable with the sockets shown.
