Page 106 - BallyMidway YELLOW Parts Catalog 16-9147-B

Cable Assemblies - cont'd
Gillign PartyZ DrWho BlackR Addam
Part Number Description 20003 20004 20006 20013 20017
Game and Part Quantity
H-15512 Ramp lamp Cable Ass'y" x
H-15513 Flasher Cable Assembly x
H-15514 Mini-Playfield Cable x I
H-15515 Back Panel Cable Ass'y x I
H-15516 Ramp Switch Cable Ass'y x
H-15517 Opto Cable Assembly x
H-15518 Playfield Switch Cable I x
,
H-15519 Playfield Lamp Cable x
H-15520 Playfield Solenoid Cable x
H-15521 Insert Cable Assembly x
H-15586 Cabinet Cable Assembly x
H-15587 Speaker Lamp Cable x
H-15588 Right Ramp Cable Ass'y x
H-15591 Home Opto Cable Ass'y x
H-15592 5-Opto Cable Assembly x
H-15593 Motor Cable Assembly x
H-15594 Mini-Playfield lamp Cbl x
"
H-15600 Middle Ramp Switch Cbl x
H-15702 Ramp Opto Cable Ass'y x ,
H-15736 Secondary Cable Ass'y x x
5795-1 0938-14 26-Pin Ribbon Cable x x x x x
5795-12653-03 34-Pin Ribbon Cable x x x x x
5795-12837-01 34-Pin Ribbon Cable x x
5795-12838-30 14-Pin Ribbon Cable x x
5795-12838-60 14-Pin Ribbon Cable x x x
5795-13018-00 34-Pin Ribbon Cable x x x
1-28m @a!fy/MIDWAY
