RAMP-LIFT ASSY.: RIGHT-PARTS LISTs CONT'D.PART NO.. AE94-00044-0000
ORDER BY PART Nut1BER ONLY
ITEM PART NO .• DESCRIPTION
21 0360-00721-00XF PIN: LINK (2 REQ I O. )
22 0365-00187-00XF PLATE: LATCH
23 * OE94-00152-00XF PUSH-ROD: RIGHT
24 0365-00713-00XF STUD: SHOULDER
25 0365-00196-29XF PLATE: SIDE; DROP-TARGET
26 0967-00105-00XF BRACKET: COIL
27 0967-00106-00XF PLATE: BOTTOM
28 0967-00109-00XF LINK: DROP-TARGET
29 0967-00113-00XF PLATE: BOTTOM-ADJUSTABLE
30 0967-00124-00XF PLATE: END; DROP-TARGET.
31 0967-00704-00XF PLUNGER
RAMP-LIFT ASSY ..: LEFT-PARTS LIST
PART NO ..AE94-00045-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO .. DESCRIPTION
23 * OE94-00151-00XF PUSH-ROD: LEFT
* IIIOTE:ALL OTHER PARTS SAME AS LISTED IN AE94-00044-0000 EXCEPT ITEM 23
6.15
