TOP PlAYFIElD ASSEMBLY WIO PlASTICS - PART LIST, CONT'D.
PART NO. AE79-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO .• DESCRIPTION
25 OE79-00107-0000 BRKT. : RAMP SUPPORT (LOCATED UNDER RAMP ENTRANCE PLATE)
26 0360-00188-00XF GUIDE: BALL RETURN
AE79-00050-0000 RAMP-STUD TO SWITCH ASSY. (INCLUDES ITEMS 27 THRU 29)
27 AE35-00014-00XF STUD TO RAMP ASY.
AE79-00049-0000 SWITCH W/BRKT. ASSY. : RAMP (INCLUDES ITEMS 28 & 29)
28 AA40-00020-0000 SWITCH W/DIODE s WIRE FORM ASSY. (2 REQ'D. )
0010-00295-0000 WIRE-FORf1: SWITCH - RAMP (2 REQ'D)
0017-00007-0015 NUT: 1/8 PUSH ( 2 REQ'D.)
0017-00032-0123 SWITCH :. MICRO~ LOW-TORQUE (2 REQ'D.)
29 OE35-00909-0000 SWITCH: 5-INSULATOR (LOCATED UNDER BALL RAMP)
30 AE35-00044-00XF REAR BALL CHANNEL & BRKT. ASSY.
31 OE35-00118-00XF BAL RUNWAY_
32 AE79-00501- 0XF PLAYFIELD W/INSERTS: SCREEND & PIERCED
33 AA17-0D023-0000 BALL REBOUND ASSY. (LOCATED UNDER FLIPPER PLATFORM)
0017-00041-0715 BUMPER: REBOUND, RUBBER
34 0370-00918-0300 BOTTOM ARCH EXTENSION
35 OE79-00121-0000 PLATE: BALL DEFLECTOR
36 0390-00906-0000 BUTON: ROLL-OVER (WHITE) (4 REQ'D. )
37 A.E35-00016-0000 FRONT BALL CHANNEL ASSY.
38 AE35-00070-0000 STOP-TO-COVER ASSY.
39 0967-00707-01XF STUD: 6-32 X 1-11/16" (7 REQ'O. )
40 OE79-00903-0000 MYLAR: PLAYFIELO CITY SLICKER
41 0017-00007- 546 BALL: 1-1/16" OIA. STEEL (INSERTED IN OUTHOLE TROUGH) (2 REQ'O. )
