1987 PINBALL GAME PARTS GUIDE
COIL/SOLENOID CROSS-REFERENCE LISTING
BALLY COIL NUMBER MIDWAY COIL & TUBING NUMBER MIDWAY COIL NUMBER
A-24-570/A-34-3600 AC70-00023-0000 A365-00067-0021
AC70-00026-0000
A-25-500/A-34-45000 A360-00045-0000 A365-00067-0009
A-26-1200 A360-00044-0000 A365-00067-00 6
A360-00046-0000
A360-00047-000
A967-00046-0000
A-27-1300 .4.360-00211-0000 .4.365-00067-0008
A967-00048-0000 .4.365-00067-0011
A-29-2100 AE79-00047-0000 A365-00067-0010
A-30-3000 AE94-00043-0000 A365-00067-0027
C-29-1500 AE47-00037-0000 A365-00067-0023
C-31-2000 A371-oo036-0000 A365-00067-0002
AE47-00039-0000 A365-00067-0003
G-31-1800 AE35-00058-0000 A365-00067-0024
G-34-4000 A390-00029-0000 A365-00067-0020
G-36-6900 AEI4-00046-0000 A365-00067-0020
A365-00067-0022
N-26-1900 A360-00209-0000 A365-0 067-0017
A967-00077-0000 A365-00067-0018
BALL CHANNEL ASSEMBLY - PARTS LIST
PART NO. M40-00027-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
1 A360-00039-0000 LEVER - ARM ASSY.: RIGHT
2 A360-00211-0000 COIL & TUBING ASSY. (2 LUGS)
3 A365-00024-0000 CORE - PLUG & BRKT. ASSY.
4 OA40-001l8-00XF SPACER BRACKET (2 REQ'D.)
5 0010-00275-0353 EXTENSION SPRING
6 0017-00042-0413 FLIPPER BEARING
7 0017-00042-0418 NYLINER: SNAP-IN, COIL
8 0017-00101-061 8-32 X 4 PHL PAN TT ST (4 REQ'D.)
9 0017-00101-0184 8-32 X 6 NO HXW TT ST (7 REQ'D.)
10 0017-00101-0480 10-32 X 6 SLT HXW S ROL ST (2 REQ'D.)
11 0017-00104-0073 WASHER .515 ...•875 ...•013 SPRGST
12 0360-00145-00XF SWITCH BRACKET
13 0360-00152-02XF BRKT.: RIGHT FLIPPER STOP
14 0360-00318 ...00XF COIL BRACKET
15 0360-00718-00XF PLUNGER
16 0365-00101-00XF BRKT.: FLIPPER MOUNTING
17 * AA40-00019-0000 BALL GATE ASSEMBLY (NOT SHOWN)
18 * OA40-00703-0000 SPACER BUSHING (NOT SHOWN)
* _OT PART OF ABOVE ASSEMBLY & MUST BE ORDERED SEPARATELY
