Page 16 - 1987_COMMON_PARTS_ASPIRE

DROP TARGET: LEFT HAND SINGLE
PART NO. AE14-00019-0000 DUAL DISPLAY MODULEA084-91851-HOOO
M051-00365-H042 (Page I of 5) REV.I
DESIGNIATION LIST
DESIGNATION NO. DESCRIPTION
Rl 1 .S"K 1/4W 5% CARBON
R2 820 OHM 1/4W 5% CARBON
R3 300K 1/4W 5% CARBON
R4 1.5K 1/4W 5% CARBON
R5 510 0 Ht~ 1/4W 5% CARBON
R6 300K 1/4W 5% CARBON
R7 1.5K 1/4W 5% CARBON
R8 820 OHM 1/4W 5% CARBON
R9 300K 1/4W 5% CARBON
RIO - R15 20K 1/4W 5% CARBON
R16 9.1K 1/4W 5% CARBON
R17 lOOK 1/4W 1% METAL FILM
R18 2.2K 1/4W 5% CARBON
Rl9 300K 1/4W 5% CARBON
R20 9.1K 1/4W 5% CARBON
R21 lOOK 1/4W 1% METAL FILM
R22 2.2K 1/4W 5% C~RBON
R23 300K 1/4W 5% CARBON
fD R24 9.1K 1/4W 5% CARBON
R25 lOOK 1/4W 1% METAL FILM
R26 2.2K 1/4W 5% CARBON
~ R27 300K 1/4W 5% CARBON
~t.' R28 9.lK 1/4W 5% CARBON
, R29 lOOK 1/4W 1% METAL FILM
R30 9.lK 1/4W 5% CARBON
R31 lOOK 1/4W 1% METAL FILM
R32 9.IK 1/4W 5% CARBON
R33 lOOK 1/4W 1% METAL FILM
R34 1.5K 1/4W 5% CARBON
R35 820 OHM 1/4W 5% CARBON
R36 300K 1/4W 5% CARBON
R37 300K 1/4W 5% CARBON
R38 1.5K 1/4W 5% CARBON
R39 IK 1/4W 5% CARBON
R40 lOOK 1/4W 5% CARBON
R41 lOOK 1/4W 5% CARBON
R42 IK 1/4W 5% CARBON
R43 1.5K 1/4W 5% CARBON
R44 300K 1/4W 5% CARBON
R45 1.5K 1/4W 5% CARBON
R46 820 OHM 1/4W 5% CARBON
R47 300K 1/4W 5% CARBON
R48 1.5K 1/4W 5% CARBON
R49 820 OHM 1/4W 5% CARBON
R50 300K 1/4W 5% CARBON
R51 lOOK 1/4W 1% METAL FILM
R52 - R57 2.2M 1/4W 5% CARBON
R58 9.1K 1/4W 5% CARBON
1.11 2.6a
