Page 87 - 1982_BALLY_PARTS_ASPIRE

BALL KICkER
ASSEMBLY
A·642-B
SOLENOID BRACKET ~~'-~==~~~~~~~~=t~~'
P'lOa. c.
COAEPLUG/
ASSEMBLY
A-Bla-30
SAUCER HOLE
KICKER ASSEMBLY SHAFT
AS428 -40 5-181-48 RETAINING
RING
P-63
RETAINING
RING
P-6316-4
Not Shown )
COTTER PIN
(Not Shown )
M-1721-7
MOUNTING BRACKET
A-643-7
SPRING
SP-100-230
COIL
.REFER TO PANEL CHARTS
BRACKET&
SPRING HOOK
ASS~EMaLY
A-642-7
TOP MOUNTED BALL KICKER
AS-2694-3
CORE PLUG ASSEMBLY
A·613-B9
COIL
REFER TO
PANEL CHAHTS
PLUNGER &
LINK ASSEMBLY
ASE·2586
COMPRESSION SPRING
SP-200-189
KICKER ARM ASSEMBLY
BALL RETURN
A·3545
STRIKER RI[lJG
C·838
BASE PLATE ASSEMBLY
A·3546
WHEN ORDERING PART. SPECIfY PART NO. AND NAME OF GAME 85
