PIO TABLE III
MEMORY COMBINATIONS AND JUMPERS FOR USE WITH MPU AS-2518·35
SPRING
SP-TOO-230
SOCKE T LOCATIONS
NAME OF GAME Ul U2 U3 U4 U5 U6 JUMPER REQUIREMENTS
XENON A E8 T1-1 EB11-38 E720-40 Same as SKATEBALL "A"
XENON B EB11-40 E811-41 E720-40 Same as SKATEBALL 'A'"
XENON C E811-1 E811-3B E720-3B E720·39 Same as SKATEBALL "8"
XENON D EB11-40 E811-41 E720-38 E720-39 Same as SKATEBALL "B"
XENON E E811-39 E720-40 E4-E12, E7-E8, E1O-E11,
E13A-E14, E29-E33, E31-E32,
E16A-E34
XENON F E811-42 E720-40 Same as XENON "E"
FLASH GORDON E834-21 E834-22 E720-52 Same as SKATEBALL "A"
E834-23 E720-52 Same as XENON HE"
EIGHT BALL E838-13 E720-52 Same as XENON "E"
DELUXE A
EIGHT BALL E838-14 E720-52 E4-E12, E7-E8, E9-E11, E13-E1
DELUXE B E29-E33, E31-E32, E16A-E34
EIGHT BALL E838-15 EnO-52 Same as XENON "En
DELUXE C
FIREBALL II E839-8 E720-52 Same as XENON "En
E839-9 E720-52 Same as EIGHT BALL
DELUXE "B"
E839-12 E720-52 Same as XENON "E"
EMBRYON E841-00 E720-52 Same as XENON HE"
E841-3 E720-52 Same as EIGHT BALL
DELUXE "s"
E841-6 E720-52 Same as XENON "E"
FATHOM E842-8 E720-53 Same as XENON "E"
E842-9 E720-53 Same as EIGHT SALL
DELUXE "B"
MEDUSA E845-9 E720-53 Same as XENON HE"
E845-11 E720-53 Same as XENON "E"
CENTAUR E848-8 E720-53 Same as XENON "E"
5,
BALL KICKER
ASSEMBLY
A·642·6
SOLENOID BRACKET ~~,-~~==~~~~~~~~~~~
P-T08 tr.
CORE PLUG/
ASSEMBLY
A-6T3-30
SAUCER HOLE
KICKER ASSEMBLY SHAFT
AS-428-40 S-181-48 RETAINING
RING
P-6316-4
RETAINING
RING
P-6316-4
(Not Shown)
COTTER PIN
(Not Show n)
M-1721:7
SPRING WASHE
MOUNTING BRACKET P-l158-6
A-643-7
COIL PLUNGER
REFER TO PANEL CHARTS S-496-38
SPRI.NG
SP-199-11
BRACKET &
SPRING HOOK
ASSEMBLY
A-642-7
TOP MOUNTED BALL KICKER
AS-2694-3
CORE PLUG ASSEMBLY
A-613-89
COIL
REFER TO
PANEL CHARTS
PLUNGER &
LINK ASSEMBLY
ASE-2586
PRESSION SPRING
SP-200-189
K ICKE R ARM ASSEMBLY
BALL RETURN
A-3545
STRIKER RING
C-838
BASE PLATE ASSEMBLY
A-3546
WHEN ORDERING PART. SPECIFY PART NO. AND NAME OF GAME WHEN ORDERING PART. SPECIFY PART NO. AND NAME OF GAME
