Page 66 - 1980_BALLY PARTS ASPIRE

FLIPP,ER
LEVER ARM (Right)
A-37l1 .
FUPPER'
LEVER ARM (Rjght)
A-3711-2
r . :;:~ _-RUBBER
R·206·9
MINI-POST
S·2122
MINI·POST
ASSEMBLY
AS·2836
_RUBBER
R.206-11
MINI-POST &
RUBBER ASSEMBLY
ASE-283S-'
POST
CLong)
C-952 ..7
POST
(Short)
C-9S1-7
ARROW TYPE PLASTIC INSERT
(PlastiC Propionate)
FUPPER
LEVER ARM (Left)
A-3711-' C·912-1 Blue C-912-4 Red C912-7 Black
C-912-2 Green C-912-5 Whi:te C-912-8 Amber
0-912-3 Purple C-912-6 Yellow 0-912c9 Red (Transl]
FLIPPER
LEVER A.RM (Left)
A-3711--3
HEX SCREW BUSHING
8-231-99
(Not Shown)
RUBBER
R-206-11
SCORING MINI POST
POST & SPRING
ASSEMBLY
-3834
SWITCH
ASW-Al-192 /
PLATE
P-318-5
BALL REBOUND ASSEM.BLY
ASE-493-6
,2 Req. ~ RUBBER NUT
~ R-412
C-667-1 Red
C-667-2 Bjue
,e·667-3 Yellow
C-667-4 Green
C-667-5 White
C-667-6 Purple
C.667-7 Amber
66 WHEN ORDERING PART, SPECIFY PART 10. AID IAIE OF GAME,
PANEL INSERT PANEL INSERT PANEL INSERT PANEL INSERT
(Plastic Propionate) (Plastic Propionate) (Plastic Propionate) (Plastic Propionate)
C-787-1 Red
C-787-2 Blue
C-78.7.3 Yellow
C-787-4 Greeen
C-787-5 White
C787-6 Purple
C-668,' Red
C-668-2 Blue
C-668.-3 Yellow
C·668-4 Green
C.668·5 White
C.668-6 Purple
C·66S·7 Amber
C-66&1 Red
C-666-2 Blue
C-666-3 Yellow
(:·666-4 Green
0.666·5 White
C,666·6 Purple
C-666-7 Amber
