DOLLY PARTON
A.
A·521
3/4" Dia.
0
B.
R·521-4
2·1/2"
Oia.
(3)
C.
R·521-3
2" Dia.
(4)
D. R·521-2
1-1/2"
Oia.
(4)
E., R·40S.3
Flippers,
(2)
F.
R·243
5/16" Dia.
(5,)
o
o
o
a
o
a
8
o
30
8
30
G
30
0000 0
0°0 0
0
0
0
o
0
00 0
o
o.
0
,27
r" ••
,.
..
_ __ 1 _ _
2&
RUBBER PARTS
Dimensions- are Inside diameters. Numbers in
parenlheses indicate quantity
used,
if
in
excess
of one.
PANEL TOP PARTS
1. Arch Rail. .. _ ....
, ... M-1J7.4
2,.
Rail
Post (2) .•........
C-907
3. Rail
Post
(2)
C-9D8
4. Bottom Arch •••......
P-5871-69
5. Shoott;!f Gauge •....•.•
P-'&359-35
6., Ball
Rebound
, .' ...
ASE-4,93-6
1 .
Ball Gate.,
, •..
A-1475-13
8.
Screened
Plastics. , ...•.
M-1330-160
9,
.,,'Wt
Assy .. IRed) (5) ,
ASE-2911-3
10.
Ball Guide
Wire
M~12t-58
11.
Thumper
Cap ..•......
A-3713·54
12.
Thumper
Cap
A-371J.55
13. ThumpetCap ....•.••.
A-3713-56
14.
Outhole
Kicker
ASE-2694-3
15.
Spinner
Gate
Ass-y...••.
ASE-2250-72
16. 8all
Gate
&.
Wire Assv ....
ASE-2250-24
11.
Target
As~y. IRecl)•.•...
A:$E-2911-31
18.
Guide R"il
Any
A-3032-37
19. Ball
GuideWire
(3) . , . _ .M-12J-18
20 .. Target Assy.
(White) ..•.
ASE·2911·20
21.
Rollover Wir,e
&
Rrlet.
(5) .ASE-2806
22. Ball Guide Wire ..••..•.
M-121-43
23.
Ball
Guide
Wire ..•.
, .•. M·121-44
24.
Butfer
Wires (2) .•.....
M-121·53
25.
Flipper
&
Shaft,Assy. {2l .ASE·2214-24
26. Outhole Wire
&
Brkt •.•..
ASE·280&-:21
27.
Shooter
Lane
Hood .•••.
P-1732
28. Ball
Guide
Wire (2) .....
M-121-34
29. Protective
Angle ...•...
P.7639
30. Thumper Body •...•
" ..
ASE"2222-4
31.
'Panel. . . . . . • . . . . . . . .CA.1128-115
WHEN ORDERING
PART.
SPECIFY PART
NO.
.
AND NAME OF BAlE
29
