RUBBER PARTS
Dimensions are inside diameters. Numbers in
parentheses indicate quantity used, if in
excessof one.
A. R·521-3
B. R-521·5
C. R·521·1
D. R·521·2
E. R·521
F. R·408·3
G. R·243
2 " Dia.
3" Dia.
1 "Dia.
1·1/2" Dia.
3/4" Dia.
Flipper
5/16" Dia.
(3 )
(5)
(1)
(1)
(1)
(2)
(5)
PANEL TOP PARTS
1. Arch Rail M·1774
2. Rail Post . . . . . . . . . . . . C·907
3. Rail Post Cap . . . . . . . .. C·908
4. Bottom Arch. . . . . . . . .. P·5871-55
5. Shooter Guide P·6359·21
6. Ball Gate (R) ....•..... A·1475-9
7. Ball Gate (L) A·1475-10
8. Screened Plastics A-2890·127
9. Thumper Cap (2) A·3713·27
10. Thumper Cap A·3713-28
11. Target Assem. (Red) . '.' . . AS-982-723
12. Drop Target Unit .•..... AS-2795-S1
13. Flipper & Shaft (2) AS·2214-24
14. Lane Hood P-1732
15. Spinner Gate (L) . . . . . . . AS-2250-41
16. Spi nner Gate (R) . . . . . .. AS·2250-42
17. Ball Gate . . . . . . . . . . . . AS·22S0·24
18 . Minipost Assem. (2) . . . . . AS-2836
19. Rollover Wire (4) . . . . . . . AS-280ti
20. Outhole Wire AS-2806-21
21. Rollover Button. . . . . . .. C·900
22. Ball Guide M-121·16
23. Ball Guide (2) M·121·18
24. Ball Guide M-121-43
25. Ball Guide M-121-44
26. Ball Guide M·121·53
CONS. - Conservative
MED. - Medium
LIB. - Liberal
Indicates movable posts for
scoring adjustments.
