Page 30 - 1979_1_PARTS_ASPIRE

~ , ,
I I
r r
, I
I•••.,
o
o 0
0000
0 0 000
000
o
o
o
o
o 0
30
STAR TREK o SWITCH ASSEMBLY IDENTIFICATION NUMBERS
o 1. Drop target (In Une) "0" (top) ASW-AT-l68
2. Drop Target (In Line) "C" ASW-Al-l68
3. Drop Target (In Line) "8" , ASW-Al-168
4. Drop Target (In Line) "Au (bottom) ASW-Al-l68
5.
6.
7. Tilt , ASW-Al-145
8. Outhole ASW-A 1-143
9.
10.
lL
12. Top (L) Flipper . _ ASW-A20-23
13. Top (A) Hipper , ASW-A20-23
14, Bottom (L) Flipper* ASW-A1D-45
15. Bottom (AI Flipper" ASW-A1D-45
16. Drop Target Aebound _ ASW-Al0-47
17. Drop Target "C" (bottom) . , ASW-Al-l68
18. Drop Target "B" _ ASW-Al-168
19. Drop Target "A" (top) ASW-Al-168
20 .
o
INDICATES SWITCH ASSEMBLY
IDENTIFICATION NUMBERS.
NOTE: CABINET: 07,16
DOOR: 06,09, to.
11, 16
INDICATES SOLENOID
IDENTIFICATION NUMBERS.
NOTE: DOOR: 10
BACKBOX: 11
CABINET: 02
INDICATES ASSEMBLY
IDENTIFICATION NUMBERS.
••ASW-A20-23 Also Used With This Switch
21.
22. Right Outlane ..... _ . , ......•...... ASW-Al-155
23. Right Flipper Feeder Lane ASW-AT-155
24. Paragon Saucer ........•... _ ASW-Al-153
25. Golden Cliffs Rollover ASW-Al0-47
26. Top Center Rollover Button, .........• ASW-A.1-162
27. 500 Point Rebound (2) ASW-Al0-47
28. Waterfall Rollover Button .. _ _ _ . ASW-A1-162
29. Center Target ASW-Al-168
30. Top Center Target. , , , . , . , .. ASW-Al-158
31. Treasure Chamber Saucer , , , , . ASW-Al-153
32. Golden Cliffs Saucer _ _ ASW-Al-153
33. Spinner. , , , , , .. , ASW-Al-151
34. Top Right _ , , ASW-A10-47
35. Right Slingshot, ,. , . _ ASW-Al0-47
3S.. Left SI ingshot. , , ASW-A 10-47
37. Bottom Thumper Bumper. ......•.. , . ,ASW-Al1O--S
38. Center Th umper Bumper , , .. ASW-A 110--S
39. Right Thumper Bumper , .. ASW-AT10--5
40. Left Thumper Bumper. , .. , _ ASW-Al10·5
D SOLENOID AND COIL IDENTIFICATION NUMBERS
1. Outhole Kicker, , , . , AN-26-1200
2. Knocker , , _ , .. , , . , , AR-26-1200
3. Treasure Chamber Saucer, AO-27-1300
4. Paragon Saucer , . ' AO-27-1300
5, Golden Cliffs Saucer, :. , AO-27-1300
6. Left Slingshot, , . , , ; , . , , AN-26-1200
7. Aight Slingshot. , , . AN-26-1200
B. Left Thumper Bumper .. , AN-26-1200
9. Right Thumper Bumper. , .. , , , . , .. AN-26-1200
10. Bottom Thumper Bumper , . , , . , . . AN-26-1200
11. Center Thumper Bumper , AN-26-1200
12. Drop Target (In Line) " .. , .. _ NO-26-1900
13. Drop Target. , . _ , . , .. , , . , N0-26-1900
14. Coin Lockout (Door) , , FO-36-7000
15. Flippers .... , .... , . , .. , , AO-25-500/34-4500
L. ASSEMBLY IDENTIFICATION NUMBERS
PANEL BOTTOM PARTS
S, Drop Target. , .. , ASE-2795-30
9. In-Line Drop Target , ASE-2993
10. Right Slingshot, ASE-2593-4
11. Left Slingshot. ..........•......... ASE-2593-4
12, Top Left Flipper , , , .ASE-1587-109
13. Bottom Left Flipper _ , , , .ASE-1587-101
14. Top Right Flipper'" , . , , , , .. ASE-1587-110
15. Bottom Right Flipper ASE-1587-102
• N a t used on German and French Models. Repl aced by Ball Guid e tlM-121-29 (2-9/16") and Post tlC·951· 7, Washer #PW-600-1112,
Washer tiP-SO1-107, Elastic Stop Nut tlM-3l9-S and Screw tiM SPR-S32-1128.
1. Top Left Saucer, , ' , , , .. ASE-428-44
2. Left Saucer , ASE-428-44
3. Right Saucer .. , , ASE-428-41
4 .. Right Thumper. , ASE-1567-13
5. Left Thumper , , . , , . , ASE-1567-13
S. Center Thumper , , . , .. , ASE-1567-13
7. Bottom Thumper .. , . , . , ,. ASE-1567-13
WHEN ORDERING PART.
SPECIFY PART NO.
AND NAME OF GAME
NOTE: Install Mini-Post Assembly tlAS-2B3S-1, T-Nut tlM·1700-S and Nut tlN-632 between lower left plastic and gate post.
For assembly breakdown, see back of book.
WHEN ORDERING PART, SPECIFY PART 10. AND NAME OF GAME
39
