Page 20 - 1979_1_PARTS_ASPIRE

KNOB & ROD
A-l00-15
COMPRESSION
SPRING
SP-247
SHOOTER GUIDE
COVER WELD
ASSEMBLY
A-3830
C-934
COMPRESSION
SPRING
SP-200-24
BACK GLASS
GT-408-34
RETAINING RING_~",
P-801-507
BALL SHOOTER
ASSEMBLY
ASE-2378-6
WHEN ORDERING PART. SPECIFY PART NO. AND NAME OF GAME
PLUMB BOB
E-138-3
BALL
SHOOTER
PLATE
P-5291
MOlEX PLUG SERVICE TOOL KIT - K-555
MOLEX HT 2038 EXTRACTOR & PIN
NOTE: The Molex Pin Extractor Tool enables easy ser-
vice of the Molex Plug_ Pins both male and female are re-
movable. Holding Extractor Tool as shown in lIIustra·
tion, placing forefinger over shaft as to hold i t from
turning (as shown), push Shaft o.••er Pin _giving Tool a
sl ight twist allowing the Pin Fins to compress easily,
thus enabling the Pin" to be pushed through Nylon
HOUsing.
NOTE: REPLACEMENT ITEMS CAN BE~ORDERED
THRU BALLY 018T. OR NEAREST MOLEX
REP. IN COUNTRY OF USE.
1 -n
EXTRACTO R HT-2038
= = 1 0
EXTRACT OR HT ·228 5
( MOLEX HT 2038 (1- - 7
/
, ..1
~<D - . ·amlMh~ '0
REPLACEMENT PART 11-17 1010.232
CR IMPER HT·1010·31 (Not Shown)
WHEN ORDERING PART. SPECIFY PART NO. AND NAME OF GAME
49 20
