Page 15 - 1979_1_PARTS_ASPIRE

TYPICAl. 61 Pl.ACES
METAl. TAB
SPECIAL INDENTED
HEX COLLAR STUD
6-32 Thread
1-11/16" Long - 8-2124
1-1/2" long - 8-2124-1
SPECIAL INDENTED
HEX COLLAR STUD
With 6-32 Thread at both ends
1-11/16" Long - S-2125
1-1/2" Long - S-2125-1
SCREW
(Used for Speaker Screw &
Thumper Bumper)
M-1786
LONG PRONG TEENUT
8-32 Thread
M-l08-9
LONG PRONG TEENUT
6-32 Thread
M-108-15
o
GATE
P-3023
REMOVE PIN
18 FOR KEY TYPICAL
3 Pl.ACES
TYPICAL 24 PLAC ES
REMO VE PI
8 FOR KEY
GATE
P-3023
COMPONENT PARTS LIST
BALL GATE BRACKET
P-3022-7
BALL GATE BRACKET
P-3022-7
1 A5 ASo2518-23 Lamp Driver Module. Complete
2 R71-R79 E-00105-242 Resistor, 20k. 5%, %:W
3 Rl-ABO. R70 E-00105-0237 Resistor, 2k. 5%, :v.W
4 RB1-A69 E-OO105-0'256 Resistor. 2.2M. %W
5 Cl E-00586-0065 Capacitor, .01 MFD, 500V
6 04-07.011-014,018-021. E-00585-0014 SCA.2N5060
025-032, 036-039, 043-046.
050-053,.057-060
7 01-03. 08-010. Q15-017. E-00585-0029 SCA, MCA106·1
0.22-024. 033-035, 040-042.
047-049,054-056
8 Ul-U4 E-00620-0037 I.C., Decoder, 145148
9 Jl,J3 E-00715-0004 28 Pin Wafer Connector
10 J4 E-00715-0013 17 Pin Wafer Connector
11 J2 E-0071S-00 14 23 Pin Wafer Connector
12 TP1, TP2, TP3 P-05399 Test Clip
BALL GATE ASSEMBLY (Right)
A-1475-9
BALL GATE ASSEMBLY (Left)
A-1475-10
WHEN ORDERING PART. SPECIFY PART NO. AND NAME OF GAME
