"G" TYPE RELAYS
"G" Type InferiCKk Relays shown on page 87
SWITCH
ACTUATOR
SEE PAGE 27
SPRING RETAINER
BRACKET
SEE PAGE 50
SWITCH BASE
SEPARATOR
.;::t:;...~--~SE E NOTE BE LOW
SPRING
SEE. TABLE BELOW
COIL
PART NUMBER
MARKEO ON WRAPPER
EYELET
GROMMET
SEE PAGE 50
SWITCH BASE SEPARATORS
Switch BaseSeparators ! used 'only as required, are 9/16 in.
by 5/16 in. with :2 hale s for switch screw,
1/32 in. thick (approx ima tely) '" SM8 -'
1116 in . thick (approx irnatelv ] .•. 5MB·2
SPRING TABLE
COLOR pART NO,
Natural (not dyed) SP·199 ·28
Red SP·199·29
Gre en SP-199·30
WHEN ORDERING PAftT, SPECIFY PART NO. AND NAME OF GAME
49
