SUPER FLIPPER UNITS SEE PAGE 246 FOR VARIATIONS
FLIPPER & PIN ASSYS.
SEE PAGE 246 FOR VARIATIONS
SCREW, NO.6, Y21N LONG,
SHAKEPROOF, TYPE 25,
SELF-TAPPING,
CADMIUM PLATED
RUBBER RINGS
SEE PLAYFIELD DIAGRAMS
COMMENCING PAGE 156
1)
o
FLIPPER BUTTON
RETAINING RING
P-2891-7
FLIPPER BUTTON ASSY.
FOUR MILLION B.C. and earlier games" .. AS'2443
As illustrated above
EXPRESSWAY and later games* AS-2443-1
As illustrated above with
Spring (ADDED) SP-459-1
FLIPPER BUTTON, PARTS RELATED TO
Pal Nut M-1314-2
Switch
FOUR MILLION B.C. and earlier games"
Left Button ASW-Al0l0
Right Button ASW·A 10-3
EXPRESSWAY and later qarnas"
Left Button ASW-Al0l0·1
Right Button ASW-A10-22
Switch Plate,
Flat P-126·155
Spring P-137-5
* See chronological list of games, page 6.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
245
