Page 115 - 1973_BALLY PARTS CATALOG ASPIRE

REPLAY COUNTER NOTES
NOTE A
Replay Counter is illustrated without Number Wheel. Com-
plete Replay Counter includes Number Wheel & Hub Assy.
AS-lS65, illustrated, page 148.
NOTE B
BAZAAR and earlier games*:
Order parts by name or description with reference to
(a) Replay Counter,
(b) Name of game
CAPERSVI LLE and later games* through JOUST:
As illustra ted, page 171, excepting
Base Plate Assy A-1768-36
Switch, Open at Zero SW-020-S4
BALLYHOO*:
As illustrated, page 171, excepting
Base Plate Assy A-1768-36
Ratchet & Shaft C-I0S1-24
Switch, Limit '.' , .. , .. , NOT OSED
KING TUT*:
As in CAPERSVI LLE.
GALAHAD and later games· through SPACE TIME
As illustrated, page 171
IEPLAY BUnON
Button Assy. . ".". A·l 729-17
Button Guide , , , " P-2768-26
Retaining Ring., , , ,. , , ... , P·2891-7
Switch
MARINER and earlier games·
FIREBALL and later games·
Switch Plate,
Flat , ' .
ASW-Al0-4
ASW-Al0·19
P-126-155
Spring , . . . .. P-137-5
Switch Protector Bracket
MARINER and earlier games· P-6366-1
FIREBALL and later games* P-7716
Washer P-80D-2
*See chronological lis t of games, page 6.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
172
