Page 87 - Bally 1971 Parts Catalog

X·
i . .
,SNAP·OllT SCORE COUNTER UNITS ISEENOTEA,al
CONT ACT PLATE ASSY.
A-2212-7
WIPER ASSY.
(NOT VISIBLE)
A-1618-3
i '
Not used in AS-1900-93, AS-l900-104 .
SWITCH ROCKE,R ARM
C-703-1 ' In AS-1900-93. AS-190D-94: ASW·M-300-1
In AS~1900-95: ASW-M-200-1'
In As-r 900-1 04, AS-1900-10'5 :ASW-M-300-1
In AS-190G-I06: ASW-M~200-1
HOLD PAWL
C-708-' ~;--::-)WW
HAIRPIN
'M-254-1 _-I-_.;::=--:::::~tt
ROLL.: PIN
, P-1637-43*
5-496·160*
PLUNGER
P·6 316;,6---.IJ!I!I~
RETAINING RING
Drive Pawl A~sy.
FASTENERS
SP-100-121
SPRING P-6813 ( Not used in AS-190Q.95; AS-1900-106
REEL LOCK
A·2214-20
BASE PLATE ASSY.
. ,
Order fasteners (nuts, screws, washers, erc .) by name
'or description with reference to (a) name of part which
Sastener secures, (b) Score Counter, (c) name of game.
*Starred components of AS.2293~5
May b~ purchased seporntely,
WHEN ORDERING PART, .sPECiFY· PART NO~ ,AND NAME O~ .GAM.
