SPINNER UNIT INDEX
CD Spinner Unit Assy . . . . . . . . . . . . . . . .. AS-2594
As described, column 3, page 131,
with reference to illustration, page 128,
plus following parts, page 136
Spinner & Switch Assy AS-2592
SECURED TO BASE PLATE
®
WITH 2 LOCKSCREW LS-632-4-510
®
@
®
®
consisting of
Cotter Pin .. . . . . . . . . . . . . . . . . . .. M-1536
Spinner Assy . . . . . . . . . . . . . . . . . .. A-3460
Spinner Bracket P-7631
Switch ASW-A120-'
SECURED TO SPINNER BRACKET
WITH 2 SCREW MS-540-11-110
Switch Plate P-137-5
Washer, Nylon (3 used) P-801-555
G)
®
® Spinner Cam Assy . . . . . . . . . . . . . . . .. AS-2596
SECURED TO RATCHET SHAFT
WITH SHEET METAL SCREW,
PHILLIPS TYPE A No.8 x 3/4 in. long
consisting of
Cam P-7629
SECURED TO SUPPORT DISC.
WITH 3 LOCKSCREW LS-832-5-510
AND 3 PLAIN WASHER . . . . . . . .. PW-8-"
@
@
@
®
Hub C-260
SECURED TO SUPPORT DISC
AND TO WASHER P-801-107
WITH 2 SCREW. . . . . . . . . . . .. MS·440-4-212
Support Disc P-7630
Washer P·801-107
Washer P·258-23
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
137
