STEPPING UNITS, FULL RESET
CONTACT-PLATE WIPER ASSY
(WIRED)
.
TORSION SPRING
SP-370
SOLDER LUG
P-405-14
RESET
PLUNGER
--L..~~~
S-496-101
RESET
PAWL
A-1766
SPRING
See page 129
SPRING
See page 129
See page 129
SPRING STOP
P-3384
WASHER FOR
WIPER ASSY.
P-801-107
SWITCH
See page 129
CORE PLUG ASSY.
I
A-613-33
STEP-UP COIL
See page 129
P-1158-6
SPRING-WASHER
(Not Visible)
C-342
GUIDE-RING
(Not Visible)
RETAINING
RING
P-3389
STEP-UP
PLUNGER
S-496-100
SECURED BY
PIVOT PIN
S-737-48
AND
ELASTIC
STOP NUT
M-319-3
BASE-PLATE ASSy.I---)'__---\--~~---"'r--~~
A-1768
IN JOUST
AND
EARLIER GAMES·
IN BALLYHOO
AND
LATER GAMES·
SEE PAGE
129
Operate Reset Plunger by hand until Ratchet resets to zero
position, i.e., until resetting movement stops. Then op~rate
St~p-up Plunger, and while holding Step-up Plunger in,
check to see that Reset Pawl rests at base of ratchet-tooth
(point at which straight and angular edges of tooth meet).
If Reset Pawl is not at base of tooth, adjust Spring-Stop
(P-3384) until Ratchet moves into position to permit Pawl
properly to engage tooth, as described. Then check unit
RATCHET
See page 129
manually by operating Step-Up Plunger. After Reset Pawl
drops into position described above. Step-Up Arm should
over-ride approximately 1/64 in. before being stopped by
Step-Up Arm Stop ("ear" (ormed in Base Plate). Bend Stop
one way or another to reduce or increase over-ride to ap-
proximately 1/64 in. Reset Pawl should then properly drop
into base of tooth, without binding, when Reset Plunger is
lightly operated (without pushing Plunger all the way in).
*
See chronological
list of games , page 6.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME Of GAME
128
