STEPPING UNITS, CONTINUOUS
Match (0-9) (00-90) Units with Bell
SEE·SAW
Match Unit AS-827 -416
As illustrated, page 118, with
Bas ePlate Assy . . . . . . . .. A -1768 -43
Coil B -26 -1100
Contact Plate (wir ed ) W - l007 -5
Plunger S-496 -162
Ratchet & Shaft. . . . . . .. C-l060
Spring, Extension SP-l00 -125
St ep -upArm Assy .. ,.,. A-1765 -19
Wiper Assy . . . . . . . . . .. AS-l046 -614
4 QUEENS
Match Unit .
As illustrated, page 118, with
B asePlate Assy _ A-1768 -43
Coil ... . . . . . . . . . . . .. B-26 -1100
Contac tPlate (wir ed) W -1123 -7
Plunger S -496 -16 2
Ra td iet & Shaft . . . . . . .. C -1060
Spring, Extension. . . . . .. SP-l00 -125
St ep -upArm Assy . . . . . .. A-1765 -19
Wiper Assy . . . . . . . . . .. AS-1046 -614
AS -827 -428
VAMPIRE
Match Unit AS-827 -421
Same as in 4 QUEENS, excepting
Contact Plate (wired) ... W -1123 -6
FIRECRACKER
Match Unit AS -827 -434
As illustrated, page 118, with
Ba sePlate Assy .
Bracket, Unit Mounting ..
Coil .
Cont ac tPlate (wir ed)
Plunger .
Ratchet & Shaft
Spring, Extension
Step -upArm Assy
Wip e rAssy
A -1768 ·43
P-5052 -16
B-26 -1100
W-l034 -10
S -496 -100
C-l050
SP - l00 -125
A -1765 -18
AS-l04 6 -501
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
