"KK" TYPE RELAYS
&
INTERLOCK RELAYS
JOUST
Standard components of "KK" Type Relays and Interlock Relays
are shown on page 41. The following components are variable.
COIL
Part number is marked on Coil Assy.
FRAME
See listing of RElAY NAMES on this and following pages for ON
BEAM and later games*.
For GATOR and earlier games*, order
Frame by name with reference to (a) name of Relay, (b) name
of game.
SPRING
Natural (not dyed)
SP-199-13
Blue
SP-199-14
Green
SP-199-17
Red
SP-199-16
Yellow
SP-199-15
SWITCH
Order by name with reference to (a) name of Relay, (b) name
of game.
If Relay uses 2 Switches, be sure to specify LEFT or RIGHT
to indicate relative position of Switch, viewed from lug side.
SWITCH PLATE
Order by name with reference to Switch, as described above.
SWITCH SCREW
Order by name with reference to Switch, as described above.
ON BEAM
ON BEAM
Single Relay
A BUMPER
B BUMPER
C BUMPER
D BUMPER
Frame "
A·604A·5
SPACE SHIP
Frame
Z·1154·3
6 Bank
1 POINT
10 POINT
100 POINT
10 Bank
1ST COIN CHUTE
2ND COIN CHUTE
3RD COIN CHUTE
Frame
A 604LP·5
ANTI·CHEAT
BALL ADVANCE
Frame
A 604L·5
CENTER TARGET
Frame
A604LD5
FREE BALL
TARGET MADE
TARGET CONTROL
Frame
...........
A·604LDP·5
1000 POINT
MATCH
Frame
A·604LD·5
Frame
_
.. A 604L·5
RESET NO.1
RESET NO.2
Frame
A·604L·5
Single Relay
LEFT THUMPER BUMPER
LOWE R THUMPE R BUMPE R
RIGHT THUMPER BUMPER
Frarne
.. A 604A 5
2ND PLAYER UP
Frame
.. A 604L 5
TOP REBOUND
Frame
A 604LD 5
6 Bank
1 POINT
10 POINT
100 POINT
Frame
....
A 604LDP 5
1000 POINT
Frame
. A 604LD 5
RESET NO 1
RESET NO.2
Erame
A 604L 5
10 Bank
10,000 POINT
5000 POINT
3000 POINT
500 POINT
SKILL HOLE
CLOSE FLIPPER
Frame
A 604L 5
SERIES
FREE BALL GATE
FREE BALL ROLLOVER BUTTON
EXIT ALLEY
Frame
A 604LD 5
14 Bank
1ST COIN CHUTE
2ND CHUTE
3RD COIN CHUTE
MULTI
PLAY
Frame
.
. A 604LP·5
ANTI CHEAT
OUTHOLE SPECIAL
BALL RETURN
PLAYER ADVANCE
MATCH
SHOOT AGAIN
Frame """"""'"
A·604L 5
NO.1 MUSHROOM BUMPER
NO.2 MUSHROOM BUMPER
NO.4 MUSHROOM BUMPER
NO.6 MUSHROOM BUMPER
Frame
A.604LD.5
CONTINUED
ON
NEXT PAGE
*
See chronological
list of games, page 6.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
