Page 17 - Bally 1971 Parts Catalog

COIN-SWITCH & REJECTOR MOUNTING ASSY.
AS.277.137 ISEENOTESA,sl
SPRING
SP-399-20
SPRING
SP-148 -~ ••
SLUG REJECTOR
MOUNT ASSY.
A-1388-31 --..{
SWITCH
MOUNTING
BRACKET
P-6692-1
COIN SWITCH WIRE
M-666-13
COIN RETURN
GUIDE ASSY.
A-2719-3
COIN GUIDE
P-6694-SERIES
SEE NOTE D
COIN GUIDE SPACER
SEE NOTE D
SLUG REJECTOR MOUNTING BRACKET
P-6C46-8
I
PUSH BUTTON I
5-1946-1 I
I
SNAP WASHER I
P-448 I
PUSH-BUTTON ASSY. I
I AS-2377 -1 I
L .J
GROMMET
R-111-8
COIN LOCKOUT
ARMATURE
P-2861-22
LOCKOUT MAGNET
E-10l-58
SECURED BY
EXTRUDED WASHER
P-2552
PLAIN WASHER
PW-8-10
LOCKSCREW
LS-832-8-S10
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
