Page 144 - Bally 1971 Parts Catalog

ROLLOVERS
Right
WIRE
SEE NOTE A
Left
TWO-DIRECTION ROLLOVERS
P-6254
P-6254-1
ONE-DIRECTION ROLLOVERS
Tension of Rollover-Switch blades which contact
Actuator should be ad jus ted (0 ins ure that Ba II rolls
over Ac ruar or freely, w it hour he s it at ing or slopping.
WIRES
Double-check Playfield Charts, commencing page
156, for exact part numbers of Rollover Wires.
ROLLOVER BUTTONS
See Playfield Charts, commencing page 156.
NOTE A
Depending on appl ic ar ion, M-133() or M-I336-10
may be used. i'ires may be recognized by dimen-
sional differences indicared in reduced size
ske rch below. M-13)(, and M-I336-IO c annor be
used inrerchangeably.
M-1336
__ -:;::::.:dJ--- 1-13/32' "--~
M-1336-10
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
222
