Page 141 - Bally 1971 Parts Catalog

TARGETSELECTORASSY. (AS-1900-S7)
CORE PLUG ASSY.
A-613-71
SCREW
MS-832-6-611
DRIVE PAWL ASSY
AS-2293-2
COMPONDJTS ~fAY BE
PURCHASED SEPARATELY
Pawl C-435-1
Plunger S-496-160
Roll Pin P-1637-43
BRACKET & SHAFT ASSY.
A-2960
BASE PLATE ASSY.
A-2214-10
SPRING
SP·100-121
LOCKSCREW
LS·832·5·510
WIPER ASSY.
A-1618 RATCHET & SHAFT
C-434
BRACKET
P-6505
ROCKER
P-4492-1
LOCKSCREW
LS -832 -5-510
CONTACT PLATE ASSY.
A-2212
TARGET SELECTOR DI SC ASSY.
A-2961
(Not included in AS-1900-S7)
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
219
