Page 118 - Bally 1971 Parts Catalog

BALL - EJECTOR ASSY S.
MOUNTING BRACKET ASSY. SHAFT
S-181-48
WASHER BRACKET & SPRING HOOK ASSY.
P-8 1-34 A-642-3
See page 187
BALL KICKER ASSY.
A-642-6
CORE PLUG ASSY.
A-613-30 RETAINING RING
P-63l6-4
SPRING
SP-100-230
COIL
COl L BRACKET
P·108
See page 187
PLUNGER
5-496-38
SCREWS
Order screws by name or description with referenc e
to (a) name of game, (b) location of Ball Ejector Assy.
on playfield, (c) part screw secur es.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
186
