Page 115 - Bally 1971 Parts Catalog

THUMPER BUMPER ASSYS. (Above Playfield)
COIL& BRACKET ASSYS. (Below Playfield)
SKIRT
A-2736
in GATOR
and earlier games*
and also
in JOUST
C-790
in ON BEAM
and later games'
excepting
JOUST
._--
SPRING
SP-248
in GATOR
and earlier games'
and also
in JOUST
SP-200-177
In ON BEAM
and later games>
excepting
JOUST
SPRING
SP-200-105
BRACKET-~
SEE PAGE 181
SEE PAGE 181
LAMP
E-125-22 CAP
C-719-SERIES
NOT INCLUDED IN ASSY. I NOT INCLUDED IN ASSY.
SPECIFY COLORS AND MARKING
SOCKET
E-120-25
FLANGE & STUD ASSY.
A-1873
PLATE (STEEL)
P-3656-1
PLATE (BAKELITE)I SEE PAGE 181
PLUNGER
S-496-118
SEE PAGE 181
SWITCH & BRACKET ASSYS.
CORE PLUG ASSY. I SEE PAGE 181 I SEEPAGE181 I
* See chronological list of games, page 6.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
180
