ZIP·A·DOOPlayfield Chari
B
DD~
17
17
,I
l_.1
1B
CONSERVAT I VE
2
(,---,J
3
164
RUBBER RINGS
D trnerrstorrsare inside d iameters .Numbers in
paren thesesindicate quantity used, if in excess
of one.
A R ·115 -4 ,Rebound
B R -521·2,1 Y .in.(3)
C R -521-3 ,2in . (2)
o
R -521 -4,2% in. (3)
E R ·392,
15/16
in.
F
R -521-5,3 in . (3)
G
R -521 -6,3% in.
H
R -406-3, Yellow (2)
R -243 ,5/16 in. (3)
PARTS
1
Top Arch
P-5839-49
2
Bottom Arch
P-5871-38
3
Shooter Gauge
P-6359-10
4
Side Rail, Left
A-2900-25
5
Side Rail, R ight
A-2900-20
6
Ball Rebound Assy
AS-493-3
Detailed under item 6, page 156
7
B a ll Gate
&
Switch Assy .
AS-1315 -5
Detailed under item 7, page 158
8
Ball Gate Cover .. .. _...
P-2996-1
9
Light Shield
&
Bushing ..
A-2890 -59
10
Bumper Cap, Red
C-719-1
11
Bumper Cap, Green
C-719-4
12
Mushroom Bumper ,Green
AS-2291-4
Cap, Green
C-616-4
Eyelet
M-122-13
P ost
C-617-8
Retaining Ring
P-2891-4
Rubber Ring
R-392
Spring Compression
SP-200-162
13
B a ll Gate
&
Wire
AS-2250-12
Bracket
P-5867-2
Wire
M-1272-11
14
Flipper, White
C-611-5
15
Bumper
C-810
COMPLETE ASSY. ,PAGE 209
16
Wire Rollover
M-1336-9
17
W ire Rollover
M-1336-10
BRACKETS FOR 16 , 17 :
SEE PAGE 222
SWITCHES FOR 16,17:
SEE PAGES 101, ETC.
18
Ball Guide Rail
P-6495-63
