KING REX Playfield Chart
20
0
0) .,:~
20
e
~ 23 B
16
0
4
0
8
17
0000
000
20
o
o
8
8
o
22
o
22
2
160
3
RUBBER RINGS
Di
ru e
nsroris
are
inside diameters.
Numbers in
p a renthes esindicate quantity used ,
if
;n excess
of on e.
A R -115 -4(Rebound)
B R-521 -2,1
Y,
in. (4)
C R ·243,
5/16
in . (5)
0
R -521 -4,2Y. in. (3)
E
R -521 -1 ,1in.
F
R-392,
15/32
in . (2)
G
R -521 -3,2 in. (3)
H
R -402,
5/16
in., jumbo (4)
R -521-7,4 in. (2)
J
R -406 -3(Flipper) (2)
PARTS
1 Top Arch
P-5839-51
P-5871-41
P-6359-71
A-2900-24
A-2900-20
AS-493-3
2 Bottom Arch
.
3 Shooter Gauge
.
4 Side Rail, Left
.
5 S ide Rail ,Right
_. .
6 B a ll Rebound Assy
.
5
As detailed, item 6, page 156
7 Ball Gate Assy .....
_.. A-1475-1
8 Light Shield
&
Bushing.
A-2890-55
9 Bumper Cap, Red ... . .
C-719-1
10 Bumper Cap, Green .. .. C-719-4
11 Mushroom Bumper ,Red AS-2291-1
As detailed, item 10, page 157
12 Target Assy . ,Red .....
AS-982-723
As detailed, item 12, page 159
13 T a rget Assy .,Y e llow . ..
AS-982-740
As detailed, item 13, page 159
14 Ball Guide Wire . . . . . ..
M-121-24
15 Ball Guide Wire . . . . . . .
M-121-20
16 B a llGuide Wire....
. ..
M-121-21
17 B a ll Guide Wire . . . . . ..
M-121-23
18 Flipper, White
C-611-5
19 Ball Guide. . . . . . . . . ..
P-6495-60
20 Rollover Wire
M-1336-10
21 Rollover Wire
M-1336-11
22 Rollover Button
C-387-5
23 Chrome Cover
P-5899-8
NOTE
Posts can be moved to increase or decrease
scoring.
" LIBERAL SCORING POSITION
• CONSERVATIVE SCORING POSITION
