Page 96 - Bally 1969 Parts Catalog

"KK" TYPE RELAYSINgi~ AI
SWITCH-SCREW
SEE NOTE B
COIL
!'OoiiO SEE NOTE B
B-326
Hexagon-Head Screw
INTERLOCK RELAYSIN6~~AI
OTE A
llustration slightly less than actual size.
033-12- 208-FO-14S-N.S.
------'-.J033-12- 214-FO 142-1-N S.
033-1?-217-FO-143 =v =r=:'>:
~~
~----~'--~ I
P-5852 I SEE NOTE EI P-5852-2 :
t t
SCORE MOTOR INgi~D I
SWITCH-ACTUATORS
(Adual Size in Profile)
Q33-12- 12S-FO-144-N.S. I
SWITCH-ACTUATOR HOLDER P-58S1
(Shown flat, actual size)
NOTE B
If part number not listed in SPECIFIC PARTS
DATA, commencing on page B, order part by
name, specifying name of relay, name of game.
(When ordering Switch or Switch-Screw for relay
with 2 Switches, be sure to specify LEFT or
RIGHT to indicate relative positions of Switches,
looked at from lug side of Switches).
NOTE C: SPRING TABLE
SP-199- I 3 - Natural (not dyed)
SP-199-14 - Blue
SP-199-15 - Yellow
SP-·199-16 - Red
SP- 199-17 - Green
NOTE 0
Used only in Score Motor Assys. on page 104.
NOTE E
P-5B52-2, which is 1/16 in. longer than P-5852 and
copper plated for easy identification, is recommended
replacement" for P-5B52 ONLY IN lC CAM POSITION.
P-5B52 should be used in other cam positions.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
103
