Page 7 - Bally 1969 Parts Catalog

ALPHABETICAL INDEX
DESCRIPTION PAGE
c
Counter,
Added Ball .••..•••.........•..•..•.•.•..•. 124
ALSO SEE Specific Parts Data, specific games
commencing with SURFERS, page 50
Ball: See Specific Parts Data, specific games
Bonus: See Specific Parts Data, specific games
Fuel Pod: See COSMOSParts Data
Replay •...•.••.•••••....•.•..••.•..••..• 121
Score •••.••....•••.••.•.•.••..•...•.••.• 119
Total Play •.••..•.••••..••.••.•..•..•....• 129
Cover,
Coin Box ••••.••..•••.••••• • • • . . • . . . • . . . •. 127
Front Door ••••••.•••••••••.••••••..•..•... 128
Rebound •..•.••.•.•.•..•.••••..•....•.... 160
CROSS COUNTRY Parts Data. • . . . • . . • • . • . . . . • . . . •. 9
CUE·TEASE Parts Data •.•...••.•..••........... 9
D
DENMARK: Coin Mechanism •...•..••..........•.. 90
Devil's Canyon: See DOGIES Parts Data
DISCOTEK Parts Data ..•••.•...•••.•••.•••.•... 29
Divider, Coin Box •.••..•....••.••..••.•.•..•. 127
DIXIELAND Parts Data ••••••...•••••••.•..••.•.• 53
Dogies Canyon: See DOGIES Parts Data
DOGIES Parts Data •...•.••..••.....••••...•... 51
Door,
Back ••..•.••....••••..•...••..••••..••.• 162
Front ••••.•••..•••.•.•.•.•••.•.......••. 128
E
Ejector: See Ball Ejector Unit
ENGLAND: Coin Mechanism
SEE UNITED KINGDOM: Coin Mechanism
Escape Assy.: See Free Ball Escape Assy.
F
SO/50 Parts Data •.•.•••.••••••.•••.•••..••••.. 27
SO/50 Unit ••••••.•.•....••...•..•...••.•.••. 27
FINLAND: Coin Mechanism •.•..•.•••..••••......• 91
Flipper Arm: See Arm
Flipper Button: See Button
Flipper Assy ••.•....••.••.•..••••..••.••. 137·140
Flipper Zipper ••.••••••••••••••••.••••••.•••• 139
FRANCE: Coin Mechanism ••.••..•.••••.•••.••.•. 91
Free Ball Escape Assy .•••...•••••.•.•••..•..•• 147
Free Ball Gate: See Gate
Front Door: See Door
Front Door Cover: See Cover
Front Door Hinge: See Hinge, Front Door
Front Door Lock: See Lock Assy.
Front Door Trim: See Trim, Front Door
Front Moulding •••.•.•••.•.••....•.••......•. 126
Front Rail Lock Assy.: See Lock Assy.
Fuel Pod: See COSMOSParts Data
Full Reset Stepping Unit: See Stepping Unit
DESCRIPTION PAGE
F
Fuse. • . . • . . • • • • • • • . • • • • • •. • ••••••••••••• 129
Fuse Block .• " .•.•••••.••.••.•.•.•••••••..• 129
G
Games List •••.••••.•••••.••••••••••••.•••.• 7
Gate,
Ball ••••..•••••.•••••••••••••••••••••.•• 157
Free Ball ••.•.••••••••••.••••••••••••• 145, 146
ALSO SEE: Free Ball Escape Assy.
Kickback Units
Gear, Score Motor ••••••••••.••••••••••••• 104, 106
Gear Box Assy., Score Motor •••••.••.•••••••• 104, 106
GERMANY: Coin Mechanism ••.••••••••••••.••..•• 92
Glass,
Back: See Backglass
Top: See Topglass
Glass Channel .•.•.•••..••••••••••.••••.•.•• 125
Glass Frame Assy ••....••..•••.•••••••••• 125, 126
GOLD RUSH Parts Data ..••••.••.•.•••••••.••..• 37
Gong Assy .•......••.•.•.•••........•..•...• 162
ALSO SEE: Bell Assy.
Sounder Assy.
GRAND TOUR Parts Data •.••.••.•••••••.••••.••• 17
Grommet: See details of various Assys.
Groovy Unit: See MINI·ZAG Parts Data
Guide,
Ball: See Specific Parts Data, specific games
Panel •••...•.•....••.••.•.•.••••.•.••... 130
Push Button, Replay. • • . . • • • • • • • • • • • • . • • • . • • . . 128
ALSO SEE: Rail, Guide
Guide Ring (Plunger): See details of various Assys.
H
HAPPY TOUR Parts Data .......•.••••.•••••.•.•. 18
HARVEST Parts Data •.•.•••.•..•.•.••••...•.••. 21
HAY ·RIDE Parts Data ••...•..•..•.•••••••••.••.. 22
Hinge, Front Door ••.•..••••.•..••••••.•.•••.. 128
Hold Button: See Button
Holder, Switch Actuator •.••.••.••••••••••••••••• 103
HOLLAND: Coin Mechanism
SEE NETHERLANDS Coin Mechanism
HOOTENANNY Parts Data •...•.•••••.•.•.••••..• , 12
Hub, Number Wheel & Hub Assy. . . • • • • • • • . . • . . • • • •• 123
Interlock Relay: See Relay
Instruction Card: See Card
Insulator: See details of various Assys.
International Coin Mechanism. . . • • • • • . • • • • • • . • •. 83-97
ITALY: Coin Mechanism ..•.....•.••••••.••.•.•.• 92
2
