SPECIFIC PARTS DATA Listed chronologically by games
ROCK MAKERS
DESCRIPTION PART NO.
Alternator . . . . . . . . . . . . .. AS 1900 101
See page 89
Backglass
Glass. . . . . . . . . . . . . . . .. G-33267
Plexiglas M·1422-24
Ban Count Unit
See Stepping Units, Fun Reset
Ball Gate Assy.
See Gate
Ban Ejector Unit,
Ban Return. . . . . . . . . . .. AS-428-22
As Illustrated. page 136
Ban Return Ejector
See Ball Ejector Unit
Ball Return Guide. . . . . . .. P 63461
Ball Return Kicker
See Ball Ejector Unit
Sail Return Trough Assv.
Ball Shooter Gauge . _
A 2R96 3
Button,Ronover
See Rollover Button
Counter,
Ban
See Stepping Units, Full Reset
Fuel·Pod
Same as Counter, Super Score,
CAPE RSVI LLE. page 43
Replay.
Same as in THE WIGGLER. page 47
Score
Same as in CAPERSVILLE.page 43
Total Play E·130-10
Flipper 8r Pin ASSV.
Top AS·2214-4
See page 138
8ottom
See page 140
Left. . . . . . . . . . . . . . .. AS·2214- 7
Right " AS-2214-6
Flipper Unit (Top) . . . . . . .. AS-1587-64
Same as AS·1587·20. page 138. E XCEPTI NG
8ase Plate P-3691-18
8racket. Switch P-126-559
Coil _ E 184246
Screw (excepting Set Screw)
Order by name or description
with reference to
(a) part which screw secures.
(b) AS·1587-64
Set Screw M-1369
Spring .. _ . . . . . . . . . . . .. SP-240-2
Switch SW-Ol0211
DESCRIPTION PART NO. DESCRIPTION PART NO.
Flipper Zipper
Same as in ROCKET III. p aqe 45
IMPORTANT: ALSO SEE PAGE 141
ALSO SloE
Switch 8r Bracket Assy .•
Flipper Zipper
Free Ball Gate
See Gate
Fuel Pod Counter
See Counter. Fuel Pod
Gate.
B~I_ _ . AS 13154
Relay, Interlock
See Relay, "KK" Type,
8 Bank
Relay, "KK" Type
Single
LEFT THUMPER BUMPER
Coil. . . . . . . . . . . . . .. C 7800·334 0
Frame _ . . . . . . . . . • .. A-604A-5
RIGHT THUMPER BUMPER
Same as LEFT THUMPER BUMPER
TOP THUMPER BUMPER
Same as LEFT THUMPER BUMPER
3 Bank
NO.1 RESET
Coil C-7800·331
Frame. . . . . . . . . . . .. A-604A 5
NO.2 RESET
Same as NO.1 RESET
NO.3 RESET
Call. Frame same a. NO.1 RESET
5 Bank
SHOOT AGAIN
Coli C-7BOO 3316
Frame " A-604L-5
FREE BALL
Coil C7800-341
Frame. . . . . . . . . . • .. A·604L·5
F RE E BALL ROLLOVE R BUT1:0N
Coil. Frame same as FREE BALL
TOP SIDE LANES
Coil. Frame as FREE BALL
TOP CENTER LANE
Coil. Frame same a. FREE BALL
8 Bank
COIN (Interlock Relay)
Coil
Latch. . . . . . . . . . .. C-7800-331
Trip. . . . . . . . . . . .. C-7800-334
Frame ......•.•.... Z-1154-3
GAME OVE R (Interlock Relay)
Coils. Frame same at COIN
CLOSE FLIPPER
Coil. C-7800-3312
Frame. . . . . • . . . . . .. A·604L·5
100 POINT
Call .............•. C-7800-333
Frame. . . . . . . . . . . .. A·604LDP 5
10 POINT
Coil. Frame same as laO POINT
1 POINT
Coil. Frame same as 100 POI NT
WHEN ORDERING PART, SPECIFY PART NO.
See NOTES B. C. page 158
Free Sail
Above panel. . . . . . . . .. M 1335-1
Below panel. . . . . AS·1587-56
Same as in SU R F E RS. page 49
Rock Crusher
Entrance AS2250·19
Gate & Bushing Assy.. A-3315
Wire M-127217
Exit AS 2250 18
Bracket.. .. . .. .. P-5867 11
Wire......... M127218
Gauge. Ball Shooter P 6359·5
Guide. Ball Return .. _ P-6346 1
Kicker
See Ball Ejector Unit
See Slingshot Kicker
Lockdown. Panel, Playfield P·6784 5
March Unit
See Stepping Unit. Continuous
Meter
See Counter. Total Play
Moveable Flippers
See Flipper Zipper
Plastic Shields (Set) M-1330-49
Playfield Panel Latch Rail
See Side Rail
Playfield Panel Lockdown _. P-67845
Rails
See Side Rails
Rebound Switch ASSV.
3 used. . . . . . . . . . . . . . .. AS 982-561
8 used. . . . . . . . . . . . . . .. AS-982-509
Both illustrated. page 135
