SPECIFIC PARTS DATA Listed chronologically by games
HOOTENANNY
DESCRIPTION PART NO.
8ackgllSl. . . . . . . . . . . . . . .. G-332·S
Ball· Trough & Switch Assy.
Same as in MOON SHOT
rrH-8.1l Gate Assys.
Gate No. 1. AS·IS87·17
As illusl.aled. page 146. with
fASTENER (Retaining Ring) .... P·6231·2
Lever Arm Assy •.............. A·1889·6
Plunger Assy A·28S7·1
Screw. Switch MS·S40·7·1I0
Switch SW·0IO·138
Gate No.2 , AS·I587·16
Same as Gate No. I. excepting
Screw. Switch MS·S40·18·1I0
Swilch , SW·120·38
F,..·II.II G.t. Wires
Gate No. I M·133S
Gate No.2.. . M·133S
R.lays. "KK" Type
Single Relay
THUMPER BUMPER
Coil C·7800·334
frame... .A·604A·S
Screw. Switch..... . .... 3·48 x 1·1/2 in.
Switch (Z·II50·21 series) .. AAAA·4IJ
S Bank
1 POINT
Coil ..... .C·78OO·333
frame.. . . . .... A·6040·S
Screw. Switch. . .. . . . .. .. .. 3·48 x1·Ij8 In.
Switch (Z·1I50·21 series). .AAA·2SJ
10 POINT
Coil. frame same as 1 POINT Relay
Screw. Switch
LEfT SWITCH. . .3·48 x 1/2 in.
RIGHT SWITCH. '. . .... 3·48 J 1·1/2 in.
Switch (1·1150·21 series)
LEFT.... . ..A·17l·9A
RIGHT... ..... .. .... AAAB·2Sl
100 POINT
Coil. frame same as I POINT Relay
Screw. Switch 3·48 x 1·1/2 in.
Switch (l·1150·21 serie., AAAA·40J
AOV. RESET
Coil . .. .. C·7800·331
frlme... . ... A·604·S
Screw. Switch
LEfT SWITCH. . 3·48 x 1/2 in.
RIGHT SWITCH... 3·48 J 1·1/2 in.
Switch (1·1150·21 series)
LEfT .... .. .A·ISH·4
RIGHT. .AAAB·26H
THUMPER CONTROL
Coil..... .. .C·7800·332
frame A·604·S
Screw. Switch 3·48 1 7/8 in.
Switch (Z·1I50·21 series) BC·9H·4
6 Bank
2St
Coil C·7800·384
frame A·6Q4C·S
Screw. Switch
LEFT SWITCH 3·48 1 1/2 in.
RIGHT SWITCH 3·48 x 1·1/2 in.
Switch (t:1I50·21 series)
LEFT. . A·ISH·4
RIGHT. .. AABC·20H
HOLD
Coil . C·78OO·3312
Frame A·604·S
Screw. Switch 3·48 x 1/2 in.
Switch (1·1150·21 series) A·16H·9A
DESCRIPTION PART NO. DESCRIPTION PART NO.
50 POINT
Coil. .. .. . .. .. . .. .. .. . C·7800·331
frame. ... . ..... A·604·5
Screw. Switch.......... . .3·48 x 1·1/16 in.
Switch (Z·1I50·21 series) .AAA·23H
ADVANCE
Coil. frame same as 50 POINT Relay
Screw. Switch... . 3·48 x 1·1/2 in.
Switch (Z·1I50·21 series) AAAB·23H
20 POINT
Detail same IS 50 POINT Relay
MATCH
Coil. . . .. C· 7800·334
frame...... .A·604·5
Screw. Switch 3·48 x 1·7/16 in.
Switch (Z·1I50·21 series) AAAA·37H
R.I.ys, Trip
12 Bank (9 and 3)
START
Coil. E·I84·187
Switch.. ..SW·102·9
Same Coil on all other relays in 9 Bank
Coil E·184·155
following references are to switches
TIl T. SW·011·17
GAME OVER.. .. SW·1I0·71
RESET
LEFT.... . .. SW·021·S
RIGHT SW·03O·6
1000 TRIP.... .. .. SW·210·26
A
LEfT .
RIGHT .
.SW·01l·17
.. SW·1I0·71
Scor.·Motor AllY AS·2215·5
Cam Assy A·2725·2
Switch
Position I
Lowest level SW·200·IOII
Second level
WIRED TO Brown·White.
White· Blue SW-010·141
OTHER switch on
second level SW·100-372
Third level. SW·240·2
Position 2
Second level
WIREO TO Brown (Plastic),
Red (PlastiC) . . ..... SW·OIO·l39
OTHER switch on
second level. SW·OIO·I40
Third level. SW·I30·13
Position 3
Second level
WIRED TO White·Black,
White· Blue SW-010·141
OTHER switch on second
second level. SW·lOO·372
Position 4
Second level SW-OIO·141
Third level SW·I20·33
Steppina Unit. Continuous
Match (0·9) Unit with Bell
Coil. .. .. .. . . . .. . (·184·205
Contact·Pllte (wired) W·I034
Rltchet .. C·IOSO
Spring SP·loo·l2S
Step-up Arm Assy A·1765·4
Wiper Assy AS·ID46·395
Stepping Unit, 511111e·Step R_t
Thumper Control Unit
Base·Plate Assy A·l168
Contact·PI.te (wired) .....•... W·looo·1
Escapement Pawl. P·3387·1
Ratchet. C·IOO·40
Reset Pawl Assy A·1766·2
Step·up Arm Assy A·1765·4
Wiper Assy AS·ID46-383
Stepping Unit, rull R••• t
Advance Unit
Blse·Plat. Assy A·1768
Contact·Pllte (wired) W·I036
Rltch.t C·IOSO·10-42
Step· up Arm Assy •.........•. A·1765·S
Switch
Operate at top SW·100-1I6
Step· up Arm $W·lOO·149
Wiper Assy AS·ID46-423
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
B
Same Switches IS A ReilY
C
Same Switches as A Relay
o
S.me Switches as A Rel.y
Same Coil in all relays in 3 Bank
Coil. .. . E·I84·156
following references are to switches
NO. I TARGH
LEfT .. .. SW·210·26
RIGHT SW·001·2
NO.2 TARGET
Same Switches as NO. I TARGET ReIlY
NO.3 TARGET
LEFT.. SW·111·3
RIGHT... . SW·ooI·2
Reset Mechanism
Coil
9 BANK. .. .. [·184·94
3 BANK.. . .. E·184·196
Core· Plug Assy.
9 BANK.... .. .... AS·586·5
3 BANK...... . .. AS·586·10
Main·Shaft
9 BANK S·I64·3O
3 BANK S·I64·42
Reset·Shaft
9 BANK A·2195·6
3 BANK A·2195·24
Tie·Rod S·1275·87
