FRONT CABINET
Front Door, Mounting Board, Playfield
(CONTINUED FROM PAGE 125)
Front Cabinet, Assembled
GLASS FRAME, PARTS RELATED TO
Glcss Frome Assy.
CONTINUED FROM PAGE 125
Moulding Assy.,
Front
Inside A-2737-8
Outside" A-3052-1
Side
Left A-3152-1
Right A-3152
Plug Bumper R-231-12
Rubber Strip' R-221-28
Latch Lever" •.••.......... P-6363
See illustration below
ILLUSTRATED IN REDUCED SIZE
Pi vot Pin
(GI~ss Frome Support) 5-468-21
Front Cabinet, Assembled
GLASS FRAME, PARTS RELATED TO
Shield, Gloss Frome
Left P-7061
Right P-7061-1
See illustration below
Stop Brocket, Gloss Frome ..... P-6665-62
Support, Gloss Frome
Left ............••..... P-7062
Right .........•.•...... P-7062-1
Latch, Mounting Boord
See Mounting Boord Latch
Leg Bolt Armor .....•......•. P-3914
Lock Plate (Coin Box)* P-3045-9
Mounting Boord Latch
Left ..................•. P-6812-1
Right ••...•...... -....•.. P-6812
(CONTINUED ON PAGE 127)
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
