Page 109 - Bally 1969 Parts Catalog

STEPPING UNITS, SINGLE-STEP RESn
A-l
STEP-UP COIL
SEE NOTE A
C·342
(Guide Ri ng)---r----~~~t_\
(Nof Visible)
P.1158·6
SPRING·WASHER
(Not Visible)
Operate Reset Plunger by hand until Ratchet resets
to zero position, Le ., until resetting movement stops.
Then operate Step-up Plunger and, while holding
Step-up Plunger in, check to see that Reset Pawl rests
at base of ratchet-tooth (point at which straight and
angular edges of tooth meet). If Reset Pawl is not at
base of tooth, adjust Spring-Stop (P-33B4) until Rat-
chet moves into position to Permit Pawl properly to
engage tooth, as described. Then check unit manual-
ly by operating Step-Up Plunger. After Reset Pawl
drops into position described above, Step-up Arm
should over-ride approximately 1/64 in. before being
stopped by Step-Up Arm Stop ("ear" formed in Base
Plate). Bend Stop one way or another to reduce or in-
crease over-ride to approximately 1/64 in. Reset Pawl
should then properly drop into base of tooth, without
binding, when Reset Plunger is lightly operated (with.
out pushing Plunger all the way in).
RESET PAWL
SP-1OO-l SEE NOTE A
R·15
~---~-P-3384
SWITCH
(IF USED)
SEE NOTE A
SP-370
SEE STEPPING UNITS NOTE
ON PAGE 82
CONT ACT -PLA TE
(WIRED) WIPER ASSY.
SEE NOTE A
NOTE A
If part number not listed in SPECIFIC PARTS DATA,
commencing on page 8, order part by name, specifying
name of unit, name of game .
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
116
