STEPPING UNITS, CONTINUOUS
Match (0-9) Units with Bell
cosr ACT .PLA TE
(WIRED) WIPER ASSY
SEE NOTE A
SPRING
SEE NOTE A
P-405-14
SP-401
P-1158-6
.sPRING-WASHER
(Not Vi si bl e)
TO SILENCE BELL
STEP-UP ARM
SEE NOTE-A
PLUNGER
SEE NOTE A
Loosen Bell by turning in counter-clockwise direction.
Lower Bell to bottom of slot in m 0 u n tin g-bracker,
Tighten Bell by turning in clockwise direction.
ADJUSTMENTS
NOTE A
See adjustment instructions, page 113.
If Part Number not listed in SPECIFIC PARTS
DATA, commencing on page 8, order part by
name, specifying narn e of Itame, name of unit.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
