How to Avoid Delay When Ordering
Parts
Always order by part number and description.
Part number must include all letters indicated.
Be sure to include name of game for which each part is ordered,
together with additional
specifications stated in the Catalog.
By reference to illustrations and detailed listing, then checking Numerical Parts List, the exact
description,
number and additional
specifications of each part may easily be determined.
TABLE OF CONTENTS
1·4
Alphabetical Index
95,96
Front Cabinet
6
Lubrication Guide
97
Front Cabinet; Front Door
7
List of Games
98
Front Door
8·55
Spec ifie Parts Data, Specific Games
99
Mounting Board; Playfield Panel
56
Introduction, General Parts Catalog
100
Playfield Panel
57·60
Coin Switch & Rejector Mounting Assy.
101
Thumper Bumper
61.62
International
Coin Mechanism Data
102
Standard Bumper
63
Alternator
103
Mushroom Bumper; Rebound Switch
64·71
International
Coin Mechanism Data
104
Bounce Switch; Lamp Socket; Sounder Assy.
73.74
Trip Relay
105
Slingshot Kicker Assy.
75,76
Trip Relay, Motorized
106
Ba II Eiecto r Assy.
77
Interlock Relay; "KK" Type Relay
107
Flipper Unit
Score Motor Switch Actuator
108
Super Flipper Unit
78
Score Motor Assy.
109,110
Flipper Zipper
79,80
Score Motor Assy., Improved Type
111
Swing Type Free Ball Gate; Rebound Barrier
82
Advance and Stepping Unit Notes
112
Swivel Type Free Ball Gate
83
Continuous Stepping Unit
113
Ball Escape Assy.
114
Target Kicker Assy.
84
Continuous Stepping Unit (Match Unit)
115
Target SeIector Assy.
85
Full Reset Stepping Unit
U6
Rollover
86
Single Step Reset Stepping Unit
117
Rollover BuHon
87
Advance Unit
118
Roll·Under
89.90
Score Counter Unit
119,120
Bracket; Wire (Gate or Barrier)
91.92
Replay Counter
121·124
Miscellaneous Parts. Playfield Panel
93
Number Wheel & Hub Assy., Replay Counter
125
Back Cabinet, Miscellaneous Parts;Gong Assy.
94
Added Balls Counter
126·134
Numerical Parts List
YOU CAN BAN K ON A
GAME
