Page 33 - 1968_BALLY PARTS CATALOG_ASPIRE

SPECIFIC PARTS DATA
SO/50
DESCRIPTION PART NO.
~ Mellor Assy AS-2215-n
Cam A•• y. . . . . . • . . • .. . .. A·2725-1
Swilch
PositiOil I
Lo...,s! level ...••..... SW·3~
Second le.e I
WIRED TO While-Red.
O'Mge-6lack ....•.. SW-OIo.l41
OTHER 2 swi tehe.s on
secOl>d teve! . . . . . . . . SW-J I( ) .ua
Taird level •••••....... SW·24(H
Fourth level
WIRED TO White-Gre"".
Red·B.lack ....•...• $W-01l)·I68
OTH ER 2 swit <hes on
10"'lh Ie"", I .•...•.• SW-200-105
Listed chronologically by games
DESCRIPTION PART NO. DESCRIPTION PART NO.
Position 2
Second teve I
WIRE0 TO Oranile (PI as I rc),
Brown (Plaslic). . . SW·OIo.I67
OTHER 2 sw itches
on second level. . . . SW·021.l-42
1l1ird Ie"", I SW·Olo.13
Position 3
Second leve I
WIRED TO While·Blaek.
White-Red , ... -, . . .. 5W·0 I(). 141
WIRED TO Brown.
Orange-Red SW-100-312
Posilion 4
Second ..,,,1
WIRED TO Yellow (Pfastie).
Orange (PI asttc 1 . . . . . SW·l 01).'384
WIRED TO Gray·Yellow,
Gn,en-Wh iIe • • . • • . •• SW-l00-421
TI1ird level .....•....... SW·I4O-IO
SI~ Unit, CocItinllOllS
Match (1).9) Unit wilh Bell
Same as in HOOTENANNY
SI~I URit, Full IIe$et
Player-up Unit
Same as ; n BUS STOP
Sleppint UIriI. SinCIe-Siep IIe$eI
TI1umper ConIlOI Un it
Same as in H·ooTENANNY
ACES HIGH
B:acqIass .•... '. . G·332-25
BaI·Return hits
Same as in GRAND TOUR
PIatic: $bieIds (Comp le!e set). . . M-1331).21
1'II,fieW I'IntI Utdl !bits
LEFT ••.•••.•...•...... A·29(1). 7
RIGHT •.••••.••.•..•... A·2900-5
Rebys, ".1:" Type
Sing le Re Iays
THlNPER BUMPER
(Left, (Anter. R igllt Bumpe rs)
Same as in HOOTENANNY
LOWER THUMPER BUMPER
Coil, Frame same as THUMPER BUMPER Relay
Sc,ew. $wit.Ch 3·48 x 1-1/16 in.
Switch (Z-USI).21 series) .• AAA·3lJ
JACK & 10
ceu ......•......... C· 7800-3315·1)
·F,ame .•..•......•... A-604·S
Screw. Sot ilth
LEFT SWITCH 3·48 • 1-3/16 in.
RIGHT SWITCH •...... 3-48 • H/16 in.
Switch (Z·llSI).21 series)
LEFT ...•.....••.•• AAD-IH·4
RIGHT .•....•...... A.AAA-37H
4 Bank
I POINT
Coil ...••.•..•.••..• C·78OQ-333
Frame .......•........ A-{;I)4D-S
Screw. Swilch ........•. 3-48. 1-1/2 in.
Swileh (Z-lIS0-21 series) .• AAAA-52J
10 POINTceu, Frame .ame as 1 POINT Relay
Screw, Switch
LEFT SWITCH ..•.•.... 3..46 • 1/2 in.
RIGHT SWITCH •...... 3-48 • 1-1/2 in.
Switch (Z·IISI).21 series I
LEFT .....••....... A·19J·4
RIGHT .....•..••••. AAAA'4JJ
100 POINT
Coli, Irame same as 1 PO INT Relay
Sc,ew. Switch .•....••••. 3·48 x 1-1/2 in.
Swileh (Z-II 51).21 senes) •.. AAAA-43J
THUMPER BUMPER
Coil .••.......•...•.. C·]8OQ-3312
fr arne. . . • . . . A·604·5
Sclew. SwitCh 3·48 • 7/8 in.
Switch IZ·IISI).21 series) .. SC·9H·4
13 Sank
SINGLE COIN
Sam. as SHEBA SINGLE COIN Relay
MULTI·COIN
Same as SHEBA MULTI·COIN .Relay
MULTI·PLAY
Same as SHEBA MULTt·PLAY Relay
ANTI·CHEAT
Same as SHEBA ANTI·CHEAT Relay
HOLD
Coil .....••.•....... C·7801).332
F, arne . . • . . . . • . . . • . . • A·604-S
screw, Switch
LEFT SWITCH. . .. . .. 3-48 • 1/2 in.
RIGHT SWITCH 3·48 x H/2 in.
Switch (Z·IISI).21 series)
LEFT .•.•.......... A-15H·4
RIGHT. . • . . • . . . . AABB-2IH
MATCH
Coi I .....•.......... C-7801).334
Flame •............... A-604-5
Screw, Switch . . . . • . . . . . 3-48 x 7/8 In.
Switch (Z·II 50- 21 ser ies) • : AC·13H·4
BALL RETURN
Coil C-781J(1.331
Frame A'604-S
Screw, SWitch
LEFT SWITCH •.•..... 3·48 • 13/16 in.
RIGHT SWITCH 3-48 • 1-1/2 in.
Switch (Z·lIS().21 series)
LEFT ............• AA-3OH
RIGHT .•..•........ AAAB-29H-4
50 PT.
Coil, Frame same as BALL RE TURN Relay
Screw, Switch 3·48 • 1-1/2 in.
Switch (Z·IlSI).21 series I. AAAB-m
PLAYER UP
Coil, Frame same as BALL RIOTURN Relay
Screw, Switch 3·48 • 1·7/16 in.
Switch (Z·IlSI).21 series I .. AAAA·62H
BONUS
Coi I, Fr.me same a. BALL RETURN Re lay
Screw, Swit'c,n
LEFT SWITCH 3·48 • 13/16 ln.
RIGHT SWITCH .....•. 3-48 ~ ,·1/2 in.
Switch (Z·IlSl>21 series)
LEFT ....•..••..•. AA·24H·4
RIGHT •.....••.••• _ AAAC-3IH
ACE
Coil ••••.•...•••••.• C-7800-3315
Ftame . . . . . . . . . . . . . . . A..j)04-5
Screw, Switch
LEFT SWITCH.. . ..•• 3·48 x 1·3/16 in.
RIGHT SWITCk l·48 ~ 1·1/16 in.
SwitCh lZ-HSI).21 senes 1
LEFT AA[)..IH·4
RIGHT. . ....•. AAAA-37H
KING
S"",e as ACE Relay
QUEEN
Same as ACE Relay
IIebys. Trip
12 Bank (6 and 6)
START
Coil E-III4-187
Switch
LEn ...........•. SW-I02-ll
RIGHT ..•..•....•.• SW-120-27
Same Coil in all otller Retays
COil .. ' .........•.... E·iB4-IS6
Following references a ll !to switches
RESET, I
LEFT ........•..••... SW-141).7
RIGHT ..•...•...•... SW-12H6
RESET .2
LE FT .....•.•••.•... SW-031·3
RIGHT SW-21i-6
RESET .3
LEFT ......•••...... 5W·01]'!
RIGHT . . • • • . . . . . . . . . SW·021·5
GAME OVER .•••........ 8W·311-3
1ST PLAYER TILT
LEFT. . .. • ••••.•. 5W-111-17
RIGHT •.........•... SW-002·9
2 CAN PLAY
LEFT. . . . . . . . .. . ... SW·202·1
RIGHT .•..•.....•... 5"'111·17
2ND PLAYER TILT ••.•..• 5W·212·.
3 CAN PLAY
Same as 2 CAN PLAY Re Iay
3RD PLAYER TI LT ••..... 5W·212-4
4 CAN PLAY
LE FT . . . . . . . • . . • . • .. . SW-1l2..s
RIGHT ............•. SW·l1H
4TH PLAYER TILT SW·212·-4
Reset Meehan ism,
Same ItS in SO/SO EXCEPTING
Brackel & C"," Ptug Assy.
RIGHT B.ANK .•...... AS-SSG-19
Brackel, Coi I P'2236-6
Core·Plug .......•. 5-1065-3
Cup, Spring .......• P-2293·~
Snap-Washer ....•... P-44B·2
Spring, ComDres.i on .• , SP-200-50
Waslie r, 1116 in. thick, 0.0. 3/4 in.,
I.O. 7/16 in P··60H22
Wuhe" 3/32 in. thiCk, 0.0. 3/4 in.,
1.0. 7/16 in. lplus) , . P·80t·123 .
LEFT BANK AS-S8G-20
Same as RIGHT BANK EXCEPTING
Black"t, Coil ..••..• P-2236'14
Reset-Arm & Spr iog Stud Assy.
RIGtn 8ANK .......• A·12S'HO
LEFT BANK A·1289-11
Switch & Brackel Assy •••. AS·982·54]
Br~ket, SwitCh _ P·126·S35
Scrow, Switch 121 MS-S41).7·110
Switch 5W·100-398
Switch-Plato p..137-S
