PLAYFIELD·PANEL, MISCELLANEOUS PARTS
ARCH and rei ated parts
Order by description, speci fy name of game
BALL·GATE ASSYS.
BALL6GATE ASSY., SEE NOTE A
MS540-1 0..110 P-137-5
A.1475-1 SWITCH
SEE NOTE B
BALL-GATE &SWITCH ASSY., SEE NOTE C
I COVER: SEE NOTE D I
SW-l 410
BALL-GATE & SWITCH ASSY. (A5-1315-3)
ICdVER FOR AS-131S-3: P-2996-21
I SUPPORT BUSHING FOR AS-1315-3: S-231-6691
BUMPER SPRING
SEE POST, SPRING, PAGE 123
CARDS, Instructions and Scores
Order by part number printed on each cord
GUIDE·RAIL ASSY.
I ACTUAL LENGTH 4-9/16 IN. --~
! 1] A-2898-1 0 I:r
I ACTUAL LENGTH 6-1/4 IN.--'"
III A-30S4 TI Uf-----"-----'
GUIDE-RAILS, PLASTIC
(WITH 2 VERTICAL WALLS)
1-1/2 in. between hole centers: C-693
Specify Color
2-1/8 in. between hole centers: C-695
Specify Color
(WITH 1 VERTICAL WALL)
1-112 in. between hole centers: C-694
Specify Color
2-1/8 in. befween hole centers: C-696
Specify Color
C-122
Specify Color
NOTES APPEAR ON PAGE 122
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
121
