FLIPPER UNITS
I
SEE NOTE A
I
Right AS-1587-14 Left AS-1587-15
A-1888-9 (Right)
A-1888-10 (Left)
MS-540-7-110
A-613-67
E-184-190
HOTE A
AS-1587-14,
AS-1587-15,
used in HOOTENANNY
through BIG DAY·, are not available,
being replaced
by Super Flipper Units illustrated on page 108.
Parts enclosed in box on page 108 may be ordered
for repair of AS-1587-14, AS-1587-15. Or the advantages
of Super Flipper Units may be incorporated into AS-
1587-14, A5-1587-15 with Special Kits described on
page 62.
A5-1587-9. AS-1587-1O, used in MOON-SHOT through
3-IN-LINE· are not available.
Only the following parts for repair of AS-1587-9,
AS-1587-10 are available.
Coil •••••.••.•..•••••
E-184-190
Set-Screw •.••.••.••.
SS-%'-28-4-1104
Spring •••••.•••..••.•
SP-240
Switch ••........••.•
SW-O10-138
Swicch-P late ....••.• P-137-5
Repair of AS-1587-9, A5-1587-10 which cannot be
effected with above parts should be effected by com-
plete replacement with Super Flipper Units (page 108),
which may be purchased with or without Switch SW-
010-138.
P-l08-53
NYLON WASHER
P-801-485
NOT INCLUDED
IN
UNIT
SP·240
P-6256
A-1889-4 (Right)
A-1889-5 (Left)
SW-Ol 0-1 38
Replacement of AS-1587-9, AS-lS87-10 with Super
Flipper Unit Requires
(A) Drilling of clearance holes in panel to
ac-
eomodote Lockserews LS-832-5-810;
(8) Use of Flipper Arm Assy. A-2747-1,
i
lIus-
trated on page 62, Flipper Arm AssY. A-2747
not being adaptable to Super Flipper Units.
·Se e ch ronol ogical lis t of gomes, pog e 7.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
