Page 107 - 1968_BALLY PARTS CATALOG_ASPIRE

BOUNCE·SWITCH
WS-5/16-S10
LAMPS SEE PAGE 67
P-126-473
SOUNDER ASSEMBLY
(AS·731·6)
P-l08-3
SW-Ol 0-144 g
C-583
SP-200-7
SPRING
(NOT VISIBLE)
S-739-8
P-2891-5 CO-27R-ll
A-1455-1---I
LAMP·SOCKETS
E- 120-25
E-120-33
JlC]J,
A-1653-1
Sounder Assembly is factory-adjusted to allow approxi-
mately 1/16 in. air-gap between bottom of Adjustment
Screw (MS-S32-IO-120) and top of Plunger, when Plung-
er is pulled all the way into co il. Increasing the air-
gap will increase the sound; decreasing the air-gap
will decrease [he sound.
E-120-127
E-120-81
E-120-99 E-120-122
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
104
