IMPORTANT NOTICE
PLEASE READ
This pinball game is equipped with a SAFETY FEATURE to prevent shocks from the solenoid
circuit when the coin door is opened. A new interlock switch assembly (part no. A-18249-1),
located at the left of the coin door opening, has been added to this game. This assembly is a
bracket containing the existing memory protect switch on the bottom and a new interlock switch
on the top. When the coin door is opened, this new interlock switch opens, breaking the
connection to the +50V and +20V winding of the transformer secondary.
A special tool called the Service Switch Actuator is provided for the servicemanltechnician that
repairs the game. This tool is painted yellow and located in a bag stapled inside the cabinet. The
Service Switch Actuator slips over the interlock switch and holds it closed while the coin door is
opened, allowing the serviceman to test and repair the solenoid circuit.
Hold the top interlock switch in, then slide the short end of the Service Switch Actuator over the
top of the interlock switch bracket and the long end over the center of the switch plunger to hold it
in.
NEW INTERLOCK SWITCH
(5643-09112-00)
SERVICE SWITCH ACTUATOR
(01-11791)
MEMORY PROTECT SWITCH
(5643-09268-00)
----i ••.~ __ ~
BRACKET
(01-12676)
INTERLOCK SWITCH ASSEMBLY
(A-I8249-1)
(A-18249-2,
JAPAN ONLY)
