MENU SYSTEM OPERATION
The Main Menu allows you to choose from several categories, which in turn lead to other menus. To
access the Main Menu, open the coin door and press the Begin Test button, then press the Enter button.
Press the Up or Down buttons to cycle through the Main Menu. Press the Enter button to access a
menu. Press the Escape button to return to the Main Menu. Press the Start button for
HELP
at any time.
Main Menu
8 B kk
M
00
eepmq enu
B.1 Main Audits
B.2 Earnings Audits
B.3 Standard Audits
B.4 Feature Audits
B.5 Histograms
B.6 Time-Stamps
P. Printouts Menu
P.1 Earnings Data
P.2 Main Audits
P.3 Standard Audits
P.4 Feature Audits
P.5 Score Histograms
P.6 Game Time Histograms
P.? Time-Stamps
P.S All Data
T. Test Menu
T.1 Switch Edges
T.2 Switch Levels
T.3 Single Switches
T.4 Solenoid Test
T.5 Flasher Test
T.6 General Illumination
T.? Sound & Music Test
T.B Single Lamps
T.9 All Lamps
T.10 Lamp & Flasher Test
T.11 Display Test
T.12 Flipper Test
T.13 Ordered Lamp Test
T.14 Goalie Test
T.15 Eject Hole Test
U. Utilities Menu
U.1 Clear Audits
U.2 Clear Coins
U.3 Reset H.S.T.O.
U.4 Set Time & Date
U.5 Custom Message
U.6 Set Game
1.0.
U.? Factory Adjustments
U.S Factory Resets
U.9 Presets
U.10 Clear Credits
U.11 Auto Burn-In
A. Adiustments Menu
A.1 Standard Adjustments
A.2 Feature Adiustrnents
A.3 Pricing Adjustments
A.4 H.S.T.D. Adjustments
A.5 Printer Adiustments
Press Escape
To move out of a menu selection.
Press Enter
To get into a menu selection.
Press Up
Increases sequence; Example A.1, A.2, A.3, A.4.
Press Down
Decreases Sequence; Example A.4, A.3, A.2, A.1.
Use Up and Down to cycle through the
selections in a menu.
Use Escape and Enter to move into and out of the
selected menu
1-8
