Power Driver Board Continued ...
J128 Not Used
J137 Not Used
J129 Not Used
J138-1 Yellow-Brown, Col 1 to playfield lamps
J138-2 Yellow-Red, Col 2 to playfield lamps
J138-3 Yellow-Orange, Col 3 to playfield lamps
J138-4 Yellow-Black, Col 4 to playfield lamps
J138-5 Yellow-Green, Col 5 to playfield lamps
J138-6 Yellow-Blue, Col 6 to playfield lamps
J138-7 Yellow-Violet, Col 7 to playfield lamps
J138-8 Key
J138-9 Yellow-Gray, Col 8 to playfield lamps
J130-1 Violet-Brown, Sol 1 to playfield coil
J130-2 Violet-Red, Sol 2 to playfield coil
J130-3 Key
J130-4 Violet-Orange, Sol 3 to playfield coil
J130-5 Violet-Yellow, Sol4 to playfield coil
J130-6 Violet-Green, Sol 5 to playfield coil
J130-7 Violet-Blue, Sol 6 to playfield coil
J130-8 Violet-Black, Sol 7 to playfield coil
J130-9 Violet-Gray, Sol 8 to playfield coil
J131 Not Used
J132 Not Used
J133 Not Used
J134-1 Not Used
J134-2 Not Used
J134-3 Key
J134-4 Not Used
J134-5 Not Used
J 134-6 Not Used
J134-7 Red-Blue, Row 6 to cabinet lamp
J134-8 Red-Violet, Row 7 to cabinet lamp
J134-9 Red-Gray, Row 8 to cabinet lamp
J135-1 Red-Brown, Row 1 to playfield lamps
J135-2 Red-Black, Row 2 to playfield lamps
J135-3 Key
J135-4 Red-Orange, Row 3 to playfield lamps
J135-5 Red-Yellow, Row 4 to playfield lamps
J135-6 Red-Green, Row 5 to playfield lamps
J135-7 Red-Blue, Row 6 to playfield lamps
J135-8 Red-Violet, Row 7 to playfield lamps
J135-9 Red-Gray, Row 8 to playfield lamps
J136-1 Key
J 136-2 Not Used
J136-3 Yellow-Gray, Col 8 to insert lamps
p.C.
Boan:!
Lag,nd
J1xx Power DrtverBoard
J2xx CPU Board
J6xx Dol MatrixControllerBoard
J9xx FllptronIe II Board
3-26
