Power Driver Board
A-12697-3
J101-1 Red, 9VAC from transformer secondary
J1 01-2 Red, 9VAC from transformer secondary
J101-3 Key
J1 01-4 Blue-White, 13VAC from transformer secondary
J1 01-5 Blue-White,
loop from J1 01-4
J1 01-6 Blue-White, 13VAC from transformer secondary
J101-7 Blue-White, loop from J101-6
J102-1 White-Red, loop from J102-2
J 102-2 White-Red, 16V AC from transformer secondary
J 102-3 White-Red, loop from J 102-4
J1 02-4 White-Red, 16VAC from transformer secondary
J102-5 Black-Yellow, 100pfromJ102-6
J 102-6 Black-Yellow, 16V AC from transformer secondary
J102-7 Key
J102-8 Black-Yellow, loop from J1 02-9
J 102-9 Black-Yellow, 16VAC from transformer secondary
J103 Not Used
J104-1 White-Blue, 50VAC to J901-1 ,2
J104-2 White-Blue, 50VAC to J901-3,5
J104-3 Key
J104-4 Not Used
J104-5 Not Used
J105 Not Used
J106-1 Not Used
J106-2 Not Used
J106-3 Not Used
J106-4 Key
J106-5 Red-White, +20V to insert flash lamps
J107-1 Not Used
J107-2 Red-Brown, 50V to playfield coils
J107-3 Red-Black, 50V to playfield coils
J107-4 Key
J107-5 Not Used
J107-6 Red-White, +20V to playfield flash lamps
J108 Not Used
J109 Not Used
J110 Not Used
J111 Not Used
J112-1 White-Green, 9.8VAC from transformer secondary
J112-2 White-Green, loop from J112-1
J112-3 White-Green, 9.8VAC from transformer secondary
J112-4 Key
J 112-5 White-Green, loop from J 112-3
l.aDa! I.aaaa.waal
t
4
t
9
J103 J102
I.
a.a a a
.1
t
7
J101
J113
J114
J115
~
l·e .•
aaaaaDaal
7
~t
m
t
34 •••••••••••••••••
1
33·..··············2
J113 Ribbon Cable, Data tolfrom J211
J114-1 Gray-Green, +12VDC to J210-7
J114-2 Gray-Green, +12VDC to J904-2; J210-6
J114-3 Gray, +5VDC to J3-3 Sound Bd; J21 0-5
J114-4 Gray, +5VDC to J3-1 Sound Bd; J904-1; J21 0-4
J114-5 Black, Ground to J3-5 Sound Bd; J904-5; J210-3
J114-6 Key
J114-7 Black, Ground to J3-4 Sound Bd; J904-4; J21 0-1
p.e.
Board Lagend
J1xx PowerDriverBoard
J2xx CPUBoard
J6xx Dot MatrixControllerBoard
J9xx FllptronlcII Board
