Opto Sw 10 PCB Assembly
A-18159
<0
i
[IT
UI
0
..,
C-
o
..•
0
LO
0
0
...•.
0
[iT
1ft
..,
<0
0
LO
0
*
C-
[ir
0
1'1)
0
0
..,
..,
0
J3
...•.
0
10000000*0000
LO
12
1
J1-1 Not Used
J1-2 Not Used
J1-3 Gray-Green, to opto transmitter Sw #45
J1-4 Gray-Black, to opto transmitter Sw #44
J1-5 Gray-Orange, to opto transmitter Sw #43
J1-6 Gray-Red, to opto transmitter Sw #42
J1-7 Gray-Brown, to opto transmitter Sw #41
J1-8 Key
J1-9 Black, Ground
J4-1 Gray-Orange, to opto transmitter Sw #53
J4-2 Not Used
J4-3 Not Used
J4-4 Key
J4-5 Orange-Black, to opto receiver Sw #53
J5-1 Gray-Red, to opto transmitter Sw #522
J5-2 Not Used
J5-3 Key
J5-4 Not Used
J5-5 Orange-Red, to opto receiver Sw #52
J2-1 Not Used
J2-2 Not Used
J2-3 Orange-Green, to opto receiver Sw #45
J2-4 Orange-Yellow, to opto receiver Sw #44
J2-5 Orange-Black, to opto receiver Sw #43
J2-6 Key
J2-7 Orange-Red, to opto receiver Sw #42
J2-8 Orange-Brown, to opto receiver Sw #41
J2-9 Gray-Yellow, +12VDC
J3-1 Black, Ground from J116-3
J3-2 Gray-Yellow, +12VDC from J116-2
J3-3 Green-Black, from J207 -5, to playfield switches
J3-4 Green-Yellow, from J207-4, to playfield switches
J3-5 Key
J3-6 Not Used
J3-7 Not Used
J3-8 White-Green, from J209-5, to playfield switches
J3-9 White-Yellow, from J209-4, to playfield switches
J3-10 White-Orange, from J209-3, to playfield switches
J3-11 White-Red, from J209-2, to playfield switches
J3-12 White-Brown, from J209-1, to playfield switches
3·14
J6-1 Gray-Brown, to opto transmitter Sw #51
J6-2 Key
J6-3 Black, Ground
J6-4 Gray-Yellow, +12VDC
J6-5 Orange-Brown, to opto receiver Sw #51
