Lamp Locations (Continued)
.an,
SY1b..
.I.D.InR.
Description
No.
No.
Assy. No.
51 24-8768
A-18384
Goal Jackpot
52 24-8768
A-18384
Extra Ball
53 24-8768
A-18384
Goal (2)
54 24-8768
A-18384
Upper Build Lock
55 24-6549
A-17835
Light Magna Goalie
56 24-6549
A-17835
Right Flipper Lane
57 24-6549
A-17835
Shoot Again
58 24-6549
A-17835
Right Special
61 24-8768
A-18072
Left Ramp Build Lock
62 24-8768
A-18072
Spinner Build Lock
63 24-8768
A-18072
Travel
64 24-8768
A-18072
Los Angeles
65 24-8768
A-18072
Left Ramp Lock
66 24-6549
A-17835
Upper Left Lane
67 24-6549
A-17835
Upper Right Lane
~
68 24-8768
A-18495
Skill Shot Front
71 24-8768
C-12709
Light Jackpot (2)
82
72 24-6549
A-17835
Final Draw
73 24-6549
A-17835
Magna-Goal Save
74 24-6549
A-17835
Left Flipper Lane
75 24-6549
A-17807
Light Kickback
76 24-8768
C-12709
Left Ramp Buy Ticket
77 24-8768
C-12709
Right Ramp Buy Ticket
78 24-8768
C-12709
Ultra Ramps (2)
81 24-6549
A-17807
Rollover 1 (High)
132 24-6549
A-17807
Rollover 2
33 24-6549
A-17807
Rollover 3
84 24-6549
A-17807
Rollover 4 (Low)
85 24-8768
A-18495
Skill Shot Rear
86 24-8768
A-18495
Skill Shot Center
87 20-9663-D-1
Buy-in Button
88 20-9663-1
Start Button
24-8768
=
#555 Bulb
24-6549
=
#44 Bulb
