A-17569
Motor Assembly
o
A-18138
Diverter Assembly
Item Part No.
Description
Item Part No.
Description
1.
01-12175.1
Motor Mount Bracket
1.
A-18152
Diverter Bracket
2.
14-7996.1
Motor - Soccer Ball
2.
01-8413-1
Coil Mounting Bracket
3.
4008-01168-10
Mach. Screw, 8-32 x 3/4"
3.
4701-00004-00
Lockwasher #10 Split
4.
20-8712-25
"E"-Ring, 1/4" Shaft
4.
4010-01008-06
Mach. Screw, #10-32 X
318'
5.
H-18601-6
Cable Assembly
5.
20-8790
Nylined Bearing
6.
FL-11753-1
Coil Assembly, Yellow
Associated Assemblies:
7.
A-10821
Flipper Stop Bracket Assembly
6.
A-17568
Plate Assembly
Associated Assemblies:
a)
A-17641
Guide, Plate
8.
A-14185
Drive Arm Assembly
b)
02-4904
Post, Plate
9.
A-16636
Diverter Plunger Assembly
7.
23-6709
Soccer Ball
10.
A-18139
Diverter Gate & Shaft Assembly
a) A-18233.1
Diverter Ball Guide Assembly
b) 02-5011
Shaft
c) 4004-01003-06
Mach. Screw, 4-40 x 3/8"
d) 20-8712-25
"E" Ring, 1/4" Shaft
