A-15758 Whirlpool Eject Assembly
Item Part Number
Description
Item Part Number
Description
1.
01-10896
House Whirpool Assembly
11.
A-14232
Photo Trans. Assembly
2.
02-4672
Armature Assembly
12. 4104-01001-06 Sh. Metal Screw, #4 x
3/8
P-PH
3.
01-8506
Base Opto Mounting - Black
13.
A-14231
LED Assembly
4.
03-8506-1
Base Opto Mounting - White
14.
01-9794
Coil Mounting Bracket
5.
10-135
Spring
15.
23-6420
Rubber Grommet
6.
AE-23-800
Coil Assembly
16.
03-7067-5
Coil Tubing
7.
03-8561
Ball Popper Cup
17.
H-16229
Opto Cable
8.
4106-01152-06 Sh. Metal Screw, #6-32 x
3/8"
18.
03-8694
Under Playfield Ramp
9.
4008-01017-04 Mach. Screw, 8-32 x
1/4
P-RH-S 19. 4006-01027-06 Mach. Screw, 6-32 x 3/8P-RWH
10. 4106-01019-06 Sh. Metal Screw, #6 x
3/8"
20.
4406-01128-00 Nut 6-32 KEPS
,r- -
GRYIYEL
WHITE WATER 2-25
